Allen-Bradley 2094-BC02-M02-S 15A Kinetix 6000 Servo Drive 400V AC Class IAM 15kW / 23A 6.6kW / 15A (Cont RMS)

1
MOQ
Negotiable
Price
Allen-Bradley 2094-BC02-M02-S 15A Kinetix 6000 Servo Drive 400V AC Class IAM 15kW / 23A 6.6kW / 15A (Cont RMS)
Features Gallery Product Description Chat Now
Features
Specifications
Warranty: 1 Year
Ram: 480GB
Controlmode: Position, Speed, Torque
Part No: IOP302
Color: Normal
Frequency: 50/60Hz
Protectionclass: IP20 To IP65
Max Frequency: 500HZ
Input Voltage: 110-240V
Payment: Union.Paypal TT
Actual Value: Negotiabled Price
Communication Protocol: CANopen, EtherCAT, Modbus
Adjustable Speed Range: 1:1000 (V/C)
Resolution Ratio: NO
Starting Torque: 0hz/180%( VC)
Highlight:

Allen-Bradley Kinetix 6000 servo drive

,

400V AC servo drive with warranty

,

15A servo drive 15kW continuous
Basic Infomation
Place of Origin: USA
Brand Name: Allen-Bradley
Model Number: 2094-BC02-M02-S
Document: 2094BC02M02S-14373-datashee...et.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 5PCS 1week
Product Description
Product Specifications
Parameter Value
Part Number 2094-BC02-M02-S
Manufacturer Allen-Bradley/Rockwell Automation
Product Line Kinetix 6000 Servo Drive
Module Classification 400V AC Class IAM
Converter Section Rating 15kW / 23A
Inverter Section Rating 6.6kW / 15A (Cont RMS)
3-Phase AC Input (Min) 324V AC RMS
3-Phase AC Input (Nom) 360-480V AC RMS
3-Phase AC Input (Max) 528V AC RMS
AC Input Frequency (Range) 47-63Hz
AC Input Nominal Frequency 50/60Hz
AC Input Nominal Current 24A RMS
AC Max Inrush Current 22A 0-Peak
DC Common Bus Input Voltage 458-747V DC
DC Common Bus Input Current 22.6A
Nominal DC Bus Output Voltage 650V DC
DC Bus Undervoltage Protection 275V DC
DC Bus Overvoltage Protection 825V DC
Shunt On Voltage 805V DC
Shunt Off Voltage 755V DC
Internal Shunt Continuous Power 50W
Internal Shunt Peak Power 5.6kW
Internal Shunt Resistor 115Ω
Continuous Output Power 15kW
Peak Output Power (Series A) 30kW
Peak Output Power (Series B-D) 37.5kW
Max Electrical Efficiency 97%
Short-Circuit Current Rating 200,000A RMS Symmetrical
Converter Inductance 500µH
Converter Capacitance 110µF
Safety Function Safe Torque Off (STO)
Compatible Axis Module 2094-BM02-S
Recommended Fuse FNQ-R-10 / FNQ-R-7.5
Recommended Circuit Breaker 1492-SPM2D060 / 1492-SPM1D150
Mounting Method Panel/Cabinet Installation
Net Weight 7.26kg (16.00 lbs)
Application Multi-axis motion control, servo motor drive, industrial automation (machine tool, packaging, printing)
Communication Protocol SERCOS III
