Home /Products/Human Machine Interface HMI/Siemens 6AV2124-0QC24-0AX0 SIMATIC HMI Compatible With Support Arm System

Siemens 6AV2124-0QC24-0AX0 SIMATIC HMI Compatible With Support Arm System

1pcs
MOQ
Negotiable
Price
Siemens 6AV2124-0QC24-0AX0 SIMATIC HMI Compatible With Support Arm System
Features Gallery Product Description Chat Now
Features
Specifications
Display Type: TFT Colour LCD
Supportedprotocols: Modbus TCP/IP, OPC UA
Resolution: 800 X 480 Pixels
Productname: Human Machine Interface (HMI)
Operatingsystem: Embedded Linux
Inputtype: Capacitive Touch
Certifications: CE, UL, RoHS
Displaytype: Touchscreen LCD
Communicationports: Ethernet, USB, RS232, RS485
Operatingtemperature: -20°C To 60°C
Powersupply: 24V DC
Memory: 128 MB RAM, 256 MB Flash
Weight: 500 Grams
Dimensions: 190mm X 140mm X 40mm
Interface: RS422, RS232, Ethernet, USB And SD Card
Highlight:

6AV2124-0QC24-0AX0

,

RoHS SIMATIC HMI
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6AV2124-0QC24-0AX0
Document: HWComfortPanelszhTW_tc-TC.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description

Product Specifications

Product Series Model Number Order Number Power Supply Power Consumption Installation Type Protection Rating Special Features
TP1500 Comfort TP1500 Comfort 6AV2124-0QC02-0AX0 24 V DC (19.2-28.8 V DC) Typ. 36 W Panel Mount (Vertical/Horizontal) Front IP65, Rear IP20 15" Widescreen TFT, 1280x800, 16M Colors, 24MB User Memory
TP1500 Comfort TP1500 Comfort 6AV2124-0QC02-0AX1 24 V DC (19.2-28.8 V DC) Typ. 36 W Panel Mount (Vertical/Horizontal) Front IP65, Rear IP20 15" Widescreen TFT, 1280x800, 16M Colors, 24MB User Memory, WEC 2013 OS
TP1500 Comfort TP1500 Comfort 6AV2124-0QC02-0AX2 24 V DC (19.2-28.8 V DC) Typ. 36 W Panel Mount (Vertical/Horizontal) Front IP65, Rear IP20 15" Widescreen TFT, 1280x800, 16M Colors, 24MB User Memory, WEC 2013 OS
TP1500 Comfort INOX TP1500 Comfort INOX 6AV2144-8QC10-0AA3 24 V DC (19.2-28.8 V DC) Typ. 41 W Stainless Steel Panel Mount Front IP66K, Rear IP20 Stainless Steel Front, Washdown Resistant
TP1500 Comfort INOX TP1500 Comfort INOX 6AV2144-8QC20-0AA3 24 V DC (19.2-28.8 V DC) Typ. 41 W Stainless Steel Panel Mount Front IP69K, Rear IP20 Stainless Steel Front, High Pressure Washdown
TP1500 Comfort Outdoor TP1500 Comfort Outdoor 6AV2124-0QC13-0AX0 24 V DC (19.2-28.8 V DC) Max. 32 W Panel Mount Front IP65, Rear IP20 Outdoor Rated, Sunlight Readable, -30°C to +60°C
SIPLUS HMI TP1500 Comfort SIPLUS HMI TP1500 Comfort 6AG1124-0QC02-4AX1 24 V DC (19.2-28.8 V DC) Typ. 36 W Panel Mount Front IP65, Rear IP20 (Conformal Coated) Wide Temp (-25°C to +60°C), Corrosion Resistant
SIPLUS HMI TP1500 Outdoor SIPLUS HMI TP1500 Outdoor 6AG1124-0QC13-2AX0 24 V DC (19.2-28.8 V DC) Max. 32 W Panel Mount Front IP65, Rear IP20 (Conformal Coated) Outdoor Rated, Wide Temp (-30°C to +60°C)
TP1500 Comfort Pro TP1500 Comfort Pro 6AV2124-0QC24-0AX0 24 V DC (19.2-28.8 V DC) Typ. 36 W Support Arm Mount (Top Flange) Front IP65, Rear IP20 Pro Version for Support Arm Systems
TP1500 Comfort Pro TP1500 Comfort Pro 6AV2124-0QC24-0BX0 24 V DC (19.2-28.8 V DC) Typ. 36 W Support Arm Mount (Round Tube) Front IP65, Rear IP20 Extendable Support Arm Structure
TP1500 Comfort Pro TP1500 Comfort Pro 6AV2124-0QC24-1AX0 24 V DC (19.2-28.8 V DC) Typ. 36 W Pedestal Mount (Bottom Flange) Front IP65, Rear IP20 Extendable Pedestal Mount

Key Features Overview

Poles: Not Applicable (N/A). Touchscreens do not have this motor‑related parameter.

Power Supply: All models are supplied by 24V DC, with a voltage range of 19.2–28.8V DC.

Power Consumption: Standard type typical power consumption 36W, stainless steel type 41W, outdoor type max. 32W.

Installation Type: Panel mount (vertical/horizontal), stainless steel panel mount, support arm mount, pedestal mount.

Protection Rating: Front protection IP65/IP66K/IP69K, rear protection IP20 for all models.
