SIMATIC Human Machine Interface HMI 24V DC 45W 650mA Siemens 6AV2124-0UC02-0AX1

The 6AV2124‑0UC02‑0AX1 is a SIMATIC TP1900 Comfort industrial touch‑screen HMI from Siemens. Powered by 24V DC, 45W, 650mA, it is used for on‑site parameter setting, real‑time data monitoring, curve display, fault alarm and system operation of automated equipment. It comes with dual‑port Ethernet switch, PROFIBUS‑DP, MPI, RS485 and USB interfaces, capable of stable connection with Siemens PLC, frequency inverters and other automation parts. Configured via WinCC Comfort/Advanced engineering software, this 18.5‑inch widescreen operator panel is built for medium and large automation production lines, process control and mechanical equipment projects.

• 18.5‑Inch Widescreen TFT Touch Display 1366×768 resolution, 16‑million‑color screen, clearly presents production data, trend curves and alarm information, supports dimmable backlight.
• Rich Industrial Communication Interfaces 2‑port integrated‑switch Ethernet, RS422/RS485, MPI, PROFIBUS‑DP, dual USB2.0, dual SD‑card slots, convenient for multi‑device networking control.
• 24 VDC Stable Power Input Rated power consumption 45W, working current 650mA, wide voltage range 19.2‑28.8V DC, adapts to complex workshop power‑supply environment.
• Large‑capacity Configuration Memory 24 MB built‑in memory, supports data logging, recipe management and alarm record storage, meets complex screen project demands.
• High‑grade Industrial Protection Front panel IP65 dust‑proof & waterproof, rear side IP20; aluminum housing, suitable for cabinet panel‑mount installation on factory site.
• Built‑in Audio Speaker Supports audible fault alarm, helps operators quickly respond to equipment abnormalities.
• International Certification Compliance Meet CE, UL, cULus, RCM, EAC, KC standards, applicable to global export automation projects.

• Packaging Machinery
• Automated Assembly Production Lines
• HVAC & Environmental Control System
• Water‑treatment Equipment
• Conveyor & Material‑handling System
• Textile, Printing & Plastic Machinery
• General Factory Automation

• Production‑line operation station
• large packaging equipment
• central air‑conditioning control cabinet
• water‑pump monitoring system
• conveyor operation terminal
• industrial oven control panel.

Warehouse reference scene for bulk supply: Suitable for industrial automation component warehouse stocking, export DDP bulk shipment.

• Net weight: 5.6 kg / pc
• Single carton gross weight: 6.35 kg / pc
• Original brand new, individual export carton, 12‑month manufacturer warranty.
