Rated input voltage:
AC 3PH 6kV, AC 3PH 10kV
Voltage fluctuation range:
-10% to +10%
Input frequency:
50/60Hz; ±5%
Input current harmonics:
Complies with IEEE519-2014 and GB/T14549-93 standards
Output voltage range:
0~6kV, 0~10kV
Output current range:
Refer to 2.4.4 Product Specifications Dimensions
Output capacity range:
0~5600kVA, 0~10000kVA
Output power range:
0~4500kW, 0~8000kW
Output frequency range:
0~120Hz (customizable for over 120Hz)
Output current harmonics:
≤2%
Control methods:
V/F control, open-loop vector control, closed-loop vector control
Control system:
DSP, FPGA, ARM
Human-machine interface:
Touchscreen
Speed ratio:
1:50 (V/F); 1:100 (open-loop vector); 1:200 (closed-loop vector)
Speed control accuracy:
±1% at maximum speed (V/F); ±0.4% at maximum speed (open-loop vector); ±0.2% at maximum speed (closed-loop vector)
Torque response time:
<200ms (open-loop vector); <100ms (closed-loop vector)
Overload protection:
120% for 60 seconds (every 10 minutes), immediate protection for 180%
Acceleration and deceleration time:
0~3600s, customizable
