Siemens 6SE6440-2UD13-7AA1 MICROMASTER 440 AC Inverter Drive Without Filter

1PCS
MOQ
Negotiable
Price
Siemens 6SE6440-2UD13-7AA1 MICROMASTER 440 AC Inverter Drive Without Filter
Features Gallery Product Description Chat Now
Features
Specifications
Control Method: V/f Control, Vector Control, Sensorless Vector
Display: LCD Or LED Display With Keypad
Power Range: 0.5 KW To 500 KW
Overload Capacity: 150% For 60 Seconds
Starting Torque: Up To 150% At 0.5 Hz
Communication Protocols: Modbus, Profibus, Ethernet/IP
Soft Start Time: 0-60 Seconds Adjustable
Mounting Type: Wall-mounted Or Panel-mounted
Frequency Range: 0-400 Hz
Cooling Method: Forced Air Cooling
Protection Features: Overvoltage, Undervoltage, Overload, Short Circuit
Soft Stop Time: 0-60 Seconds Adjustable
Output Voltage: 0-480V AC
Ambient Temperature: -10°C To 50°C
Input Voltage: 200-480V AC
Highlight:

Siemens 6SE6440-2UD13-7AA1

,

MICROMASTER 440 AC Inverter Drive

,

Siemens AC Inverter Drive
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SE6440-2UD13-7AA1
Document: 6SE6440-2UD13-7AA1_datashee...en.pdf
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 10pcs 1week
Product Description
Parameter CategoryParameter NameValue
General Information
 Product TypeMICROMASTER 440 AC Inverter Drive
 Order Number6SE6440-2UD13-7AA1
 Product StatusSpare Part (Discontinued Series)
 DescriptionWithout filter, 380-480 V 3 AC, constant torque 0.37 kW
 Protection ClassIP20 (NEMA 1)
 Construction TypeWall-mounted, chassis design
 Included AccessoriesBasic Operator Panel (BOP) optional (6SE6400-0BE00-0AA0)
Input Specifications
 Input Voltage380-480 V 3 AC
 Voltage Tolerance+10% / -10%
 Input Frequency47-63 Hz
 Input Current Rating2.2 A (at 400 V)
 Number of Phases3
Output Specifications
 Rated Output Power (Constant Torque)0.37 kW (0.5 HP)
 Rated Output Power (Square-Law Torque)0.37 kW (0.5 HP)
 Rated Output Current1.1 A (at 400 V, 50 Hz)
 Output Voltage0...0.98 × Input Voltage
 Output Frequency Range0...650 Hz (V/f control), 0...650 Hz (vector control)
 Carrier Frequency2...16 kHz (adjustable)
Overload Protection
 Overload Capacity (S1 Duty)100% of rated current continuously
 Overload Capacity (S2 Duty 60s)150% of rated current
 Overload Capacity (S2 Duty 3s)200% of rated current
 Cooling TypeForced air cooling (internal fan)
Control Modes
 Control Modes SupportedV/f control, Sensorless Vector Control, Flux Current Control
 Speed Control Accuracy±0.01% (Sensorless Vector), ±0.1% (V/f)
 Torque Control Accuracy±10% (Sensorless Vector)
 Starting Torque150% at 0.5 Hz (Sensorless Vector)
Communication Interface
 Built-in InterfacesRS485 (Modbus RTU, USS protocol)
 Optional Communication ModulesPROFIBUS DP (6SE6400-1PB00-0AA0), DeviceNet (6SE6400-1DN00-0AA0), CANopen (6SE6400-1CB00-0AA0)
Dimensions
 Width73 mm (2.87 in)
 Height173 mm (6.81 in)
 Depth149 mm (5.87 in)
 Form FactorSize A
Weights
 Net WeightApprox. 1.5 kg (3.31 lb)
Environmental Conditions
 Operating Temperature Range0°C to 40°C (32°F to 104°F)
 Storage Temperature Range-25°C to 70°C (-13°F to 158°F)
 Relative Humidity5% to 95% (non-condensing)
 AltitudeUp to 1000 m (3281 ft) without derating; 1000...2000 m (3281...6562 ft) with derating
 Vibration Resistance0.5 g (5 Hz...9 Hz), 0.1 g (9 Hz...150 Hz)
Standards Approvals
 CE MarkYes
 UL CertificationYes
 CSA CertificationYes
 RoHS ComplianceYes
 EMC ComplianceEN 61800-3 (Category C2) without filter
Additional Features
 Braking ChopperOptional (external, 6SE6400-4BD13-0AA0)
 Braking ResistorOptional (external, 6SE6400-4BR13-0AA0)
 Analog Inputs2 (0...10 V, 0...20 mA, or -10...+10 V)
 Digital Inputs3 (PNP/NPN selectable)
 Digital Outputs1 (relay contact, 250 V AC, 2 A)
 Analog Outputs1 (0...20 mA or 0...10 V)
