Home /Products/Variable Frequency Drives VFD/Milano KV90-045G-4-PV 380V Three Phase Overall Dimensions：420H(mm) 255W(mm) 210D(mm) Mounting Dimensions：405A(mm) 95B(mm)

Milano KV90-045G-4-PV 380V Three Phase Overall Dimensions：420H(mm) 255W(mm) 210D(mm) Mounting Dimensions：405A(mm) 95B(mm)

1pcs
MOQ
Negotiable
Price
Milano KV90-045G-4-PV 380V Three Phase Overall Dimensions：420H(mm) 255W(mm) 210D(mm) Mounting Dimensions：405A(mm) 95B(mm)
Features Gallery Product Description Chat Now
Features
Specifications
Output Frequency: 0-400 Hz
Input Frequency: 50/60 Hz
Output Voltage: 0-480V AC
Protection Features: Overvoltage, Undervoltage, Overcurrent, Short Circuit, Overheating
Display Type: LCD Or LED Display
Enclosure Rating: IP20 To IP54
Control Method: V/F Control, Vector Control, Sensorless Vector Control
Operating Temperature Range: -10°C To 50°C
Overload Capacity: 150% For 1 Minute
Cooling Method: Forced Air Cooling
Application: Pumps, Fans, Conveyors, HVAC Systems
Input Voltage: 200-480V AC
Mounting Type: Wall-mounted Or Panel-mounted
Communication Protocols: Modbus, Profibus, Ethernet/IP
Power Rating: 0.5 KW To 500 KW
Highlight:

380V three phase VFD

,

Milano KV90 variable frequency drive

,

industrial VFD with mounting dimensions
Basic Infomation
Place of Origin: China
Brand Name: Milano
Model Number: KV90-045G-4-PV
Document: Datesheet.xlsx
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Milano KV90-045G-4-PV 380V Three Phase Variable Frequency Drive
Physical Dimensions

Overall Dimensions: 420H (mm) × 255W (mm) × 210D (mm)
Mounting Dimensions: 405A (mm) × 95B (mm)

Product Specifications
Parameter -S2 (220V Single-Phase) -I (220V Single-Phase) -4 (380V Three-Phase)
Input Voltage Range (PV) 190-450V 190-450V 270-900V
Recommended Voc Voltage 300-400V 300-400V 450-700V
Optimum MPPT Voltage 310V 310V 540V
Maximum MPPT Efficiency up to 99% up to 99% up to 99%
Start-up Voltage 240V 240V 350V
Minimum Operating Voltage 190V 190V 270V
Input Voltage Range (AC) 1PH 220-240V(±10%) 1PH 220-240V(±10%) 3PH 380-480V(±10%)
Input Voltage Frequency 50/60Hz 50/60Hz 50/60Hz
Output Voltage Range 0-230V 0-230V 0-480V
Output Frequency Range 0-400Hz 0-400Hz 0-400Hz
Output Power Range 0.75-4kW 0.75-4kW 0.75-185kW
Rated Output Current by Power Rating
Power (kW) Rated Current -S2 (A) Rated Current -I (A) Rated Current -4 (A)
0.75952.7
1.51373.7
2.218105
323137
428179
5.5402513
7.5603217
11754525
15906032
18.51107537
221509045
3017611060
3721015075
45176110
55210150
75176
90210
110250
132300
160340
185400
Technical Features
  • Motor Compatibility: Single phase motor, Asynchronous motors, Permanent magnet synchronous motor
  • Control Modes: V/F control, Open-Loop Vector Control, Closed-Loop Vector Control
  • Overload Capacity: 150% of rated load for 60s; 180% overload capacity for 10s; 200% overload capacity for 0.5s
  • Installation: Wall-mounted
  • Protection Class: IP20
  • Working Temperature: -10°C to +50°C (derating 2% per 1°C above 40°C)
  • Cooling Method: Forced air cooling
  • Humidity: 20% to 95% RH (condensation free)
  • Installation Environment: Up to 1000m altitude (derating 1% per 100m above 1000m)
