INOVANCE MD810-50M4T1.5G200 High-Precision Servo System Multi-Axis Synchronized Motion

The MD810-50M4T1.5G200 is a high-precision multi-axis servo drive from INOVANCE’s flagship MD810 series, rated at 50A with support for up to 4 servo axes in a single compact unit with 220V class three-phase input. Designed for applications demanding superior motion accuracy and ultra-smooth trajectory control, this drive combines advanced EtherCAT real-time communication with high-resolution 24-bit encoder feedback and enhanced vibration suppression algorithms. It is ideally suited for semiconductor wafer handling, high-precision laser processing, electronic component placement, medical device manufacturing, precision metrology equipment and laboratory automation where micron-level positioning accuracy, minimal velocity ripple and flawless multi-axis coordination are critical quality requirements.

• High-Precision Servo System — 50A rated output with 24-bit absolute encoder support and advanced feed-forward control delivers sub-micron positioning repeatability and ultra-low velocity ripple for precision-critical processes.
• Multi-Axis Synchronized Motion — EtherCAT bus with sub-millisecond deterministic cycle time and electronic camming/gearing functions enable flawless coordinated motion for multi-axis gantry, pick-and-place and contouring applications.
• Advanced Vibration Suppression — Five-channel adaptive notch filters with automatic mechanical resonance detection and model-based damping control eliminate vibration artifacts, ensuring smooth motion profiles in sensitive precision equipment.
• Common DC-Bus Efficiency — Modular shared DC-bus architecture with intelligent energy management recovers regenerative power across axes, reducing heat generation and maintaining thermal stability critical for precision environments.
• Ultra-Low Noise Operation — Optimized PWM modulation with spread-spectrum switching and integrated EMI filtering minimizes electromagnetic interference, protecting nearby sensitive instrumentation and sensor systems.
• Integrated Functional Safety — Built-in STO (SIL3/PLe), SS1 and SS2 safety functions as standard, ensuring operator protection in semi-automated precision manufacturing cells and collaborative workspaces.

Semiconductor Wafer Handling & Inspection Systems, High-Precision Laser Cutting & Marking Machines, SMT Pick-and-Place & Electronic Assembly, Medical Device & Laboratory Automation, Precision Metrology & 3D Coordinate Measurement, Optical Lens Grinding & Polishing Equipment, Printed Circuit Board (PCB) Drilling & Routing, Precision Dispensing & Adhesive Bonding Systems.
