INOVANCE H3U‑8064MT

80DI 64DO NPN‑Transistor Motion PLC｜AC 100‑240VAC

1. Product Overview

The INOVANCE H3U‑8064MT belongs to H3U‑series high‑performance programmable logic controller with large‑capacity onboard I/O points. It is equipped with 80 digital inputs and 64‑point NPN transistor outputs, compatible with NPN / PNP sensor input mode. Powered by AC 100‑240VAC, it performs logic processing, high‑speed pulse acquisition, multi‑axis motion positioning, signal interlock and mass‑data collection for large‑scale automation machinery. Multiple industrial communication interfaces enable stable connection with HMI, servo drives and field sensors, ideal for automated equipment requiring massive switching‑signal and motion‑control capacity.

2. Core Advantages & Key Features

• Large‑capacity Built‑in Local I/O 80‑point digital input & 64‑point NPN transistor output; compatible with NPN / PNP sensor input; 8‑channel 200kHz high‑speed pulse input for fast signal capture.
• High‑speed Processing Performance Basic instruction execution speed 100 ns; 64 k‑steps program memory; battery‑free flash storage for program & recipe data.
• Powerful Motion Control Capacity 5‑channel 200kHz high‑speed pulse output, supporting S‑curve acceleration & deceleration, electronic cam, linear / circular interpolation for multi‑axis positioning equipment.
• Rich Industrial Communication Interfaces Built‑in 100Mbps Ethernet (Modbus‑TCP), RS485 Modbus‑RTU, CANopen / CANlink field‑bus and USB programming port. Realize seamless data exchange with HMI, servo and third‑party automation devices.
• Flexible I/O Expandability Supports local and remote extension modules, max up to 7936 remote digital I/O points for equipment function upgrade.
• Wide‑range AC Power Supply AC 100‑240 VAC wide‑voltage input, adapts to unstable workshop power grid; built‑in 24VDC sensor power output.
• Transistor Output for Motion Application NPN transistor output, suitable for driving servo & stepper systems, high‑speed pulse motion control scenarios.
• Industrial‑grade Reliability Over‑current, over‑voltage and short‑circuit protection, strong anti‑interference performance for cabinet‑mount installation.
• Convenient Programming Tool Programmed by AutoShop software, supports ladder‑diagram and multiple IEC‑61131‑3 programming languages for project development, debugging and maintenance.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Applicable Industries

• Packaging Machinery
• Woodworking Equipment
• Large Conveyor Production‑lines
• Textile Machinery
• Printing Equipment
• Automated Assembly Lines
• General Factory Automation requiring multi‑axis motion

Typical Equipment

Large‑size automatic assembly machine, long conveyor control system, large packaging production‑line, wood‑working processing equipment, sorting system, custom automation machinery with massive I/O and servo‑motion demands.

Warehouse reference scene for bulk supply: Suitable for industrial automation component warehouse stocking, export bulk shipment.

5. Packing & Logistics Reference

• Net weight: 2.85 kg / pc
• Single carton gross weight: 3.15 kg / pc
• Original brand new, individual export carton, 12‑month manufacturer warranty.
