Note:H3U‑3624MT is original CPU unit, 36 inputs and 24 NPN transistor outputs integrated on main unit
The INOVANCE H3U‑3624MT belongs to the H3U series high‑performance compact programmable logic controller. This main unit is configured with 36 digital inputs and 24 NPN transistor digital outputs, powered by AC 100‑240VAC. It features 100ns basic instruction processing speed and 64K‑step program memory, 9552‑word data register. Equipped with 8‑channel 200kHz high‑speed input, 5‑channel 200kHz high‑speed pulse output, together with Ethernet, RS485 Modbus‑RTU, CANopen/CANlink and USB communication interfaces.
It is used to implement equipment logic sequence control, high‑speed positioning, multi‑axis motion interpolation, data acquisition and inter‑device interconnection for automated machinery. Input terminals support both NPN and PNP sensor signals, NPN transistor output is optimized for driving servo and stepper drivers. It can connect HMI, frequency converters, servo drives and sensors to realize complete machine automation control, widely used in small‑to‑medium automated equipment and production lines.
| Item | Specification |
|---|---|
| Model | H3U‑3624MT (Original CPU Main Unit) |
| Brand | INOVANCE |
| Total Digital Input | 36 Points, support NPN / PNP |
| Total Digital Output | 24 Points, NPN Transistor Output |
| Power Supply | AC 100‑240VAC, 50/60Hz |
| Basic Instruction Speed | 100 ns |
| Program Memory | 64K Steps |
| Data Register | 9552 Words |
| High‑speed Input | 8 × 200 kHz |
| High‑speed Pulse Output | 5 × 200 kHz |
| Motion Function | 2‑axis linear / circular interpolation, S‑curve acceleration & deceleration, electronic cam |
| Communication Interfaces | Ethernet Modbus‑TCP, RS485 Modbus‑RTU, CANopen, CANlink, USB |
| Programming Software | AutoShop |
| Installation | DIN‑rail mounting / Screw panel mounting |
| Operating Ambient Temperature | -10℃ ~ +55℃ |
| Protection Grade | IP20 |
| Certifications | CE, RoHS compliant |
Automatic assembly machines, multi‑station conveyor lines, positioning packaging machines, material feeding systems, textile looms, wood engraving equipment, material sorting systems, servo positioning equipment.
Warehouse reference scene for bulk supply: Suitable for industrial automation component warehouse stocking, export DDP bulk shipment.
