INOVANCE H3U Series H3U-2416MR,24 Inputs 16 Outputs Relay

INOVANCE H3U‑2416MR

Product Title

INOVANCE H3U‑2416MR H3U Series PLC 24IN 16OUT Relay Output 100‑240VAC High‑speed Motion Controller

1. Product Overview

The INOVANCE H3U‑2416MR belongs to the H3U series compact modular PLC, a high‑performance programmable logic controller for industrial automation control. It delivers reliable logic operation, high‑speed pulse motion control, data processing and serial communication functions. Equipped with 24 digital inputs and 16 relay outputs, compatible with NPN/PNP sensor signals, powered by universal AC 100‑240VAC supply. It supports up to 6‑channel 200kHz high‑speed pulse output, 100ns instruction processing speed and 64K program steps. Widely deployed to control actuators, sensors, motors and peripheral devices, it executes sequence logic, positioning motion, production‑line interlock and equipment automatic operation for small‑to‑medium automation machinery.

2. Core Advantages & Key Features

✅ Universal Power Supply & Flexible I/O AC 100‑240VAC wide‑range power input; 24‑point digital input supports both NPN and PNP; 16‑point relay output, suitable for resistive and inductive load driving.

✅ Ultra‑fast Processing Performance Basic instruction execution time as low as 100ns, maximum program storage up to 64K steps, handles complex logic and multi‑task operation stably.

✅ Powerful High‑speed Motion Control Built‑in 6 channels × 200kHz high‑speed pulse output, supports multi‑axis position control, electronic cam and interpolation function for positioning equipment.

✅ Rich Communication & Expansion Capacity Multiple serial ports for serial communication; supports expansion modules to increase I/O points, analog modules and special function modules, flexible for system upgrade.

✅ Stable Industrial‑grade Hardware Anti‑interference circuit design, adapts to harsh factory workshop environment; compact body saves cabinet space.

✅ Easy Programming & Maintenance User‑friendly programming software, convenient program upload/download, real‑time monitoring and fault diagnosis, shorten equipment commissioning cycle.

✅ Complete Industrial Certifications Meets international industrial standards, qualified for overseas export automation projects.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Main Industries

• Packaging Machinery
• Conveyor & Material Handling Equipment
• Textile Machinery
• Woodworking Machinery
• Printing & Labeling Equipment
• Automatic Assembly Line
• Food Processing Machinery
• General Industrial Automation Equipment

Typical Application Scenarios

Automatic packaging machines, multi‑axis positioning platforms, conveyor systems, sorting equipment, textile looms, small‑size production lines, feeding machines, labeling machines.

5. Packing & Logistics Reference

• Original brand new unit, individual factory carton packaging
• Standard manufacturer warranty
• Suitable for bulk stock in automation component warehouse, export DDP / FOB bulk order shipment
