INOVANCE H3U‑2416MT H3U Series PLC 24IN 16OUT Transistor NPN 100‑240VAC High‑speed Motion Controller

1. Product Overview

The INOVANCE H3U‑2416MT belongs to H3U series high‑performance compact programmable logic controller. Equipped with 24 digital inputs and 16 NPN transistor outputs, wide‑range AC 100‑240VAC power supply, input terminals support both NPN / PNP sensor signals. Basic instruction execution speed up to 100ns, max program storage 64K steps, data register 9552 points. Built‑in multi‑channel 200kHz high‑speed pulse output for multi‑axis positioning control. It executes logic sequence, motion positioning, data acquisition and equipment interlock control for medium‑small automated machinery, widely used for motion‑demanding automation equipment.

🖼️ Suggested image:I/O terminal marking diagram

2. Core Advantages & Key Features

✅ Wide‑range AC Power & Flexible Input Signal AC 100‑240VAC universal power supply; 24‑point DI supports NPN & PNP sensors, adapts diverse field sensor wiring.

✅ Transistor Output for High‑speed Motion 16‑point NPN transistor output, suitable for high‑frequency pulse output; perfect to drive servo & stepper drives, cannot drive heavy inductive loads directly.

✅ Ultra‑fast Processing Performance Basic instruction scan time 100ns, 64K steps program memory, 9552 data registers, handles complex logic & multi‑task stably.

✅ Powerful High‑speed Pulse Motion Control Built‑in 6 channels ×200kHz high‑speed pulse output, support S‑curve acceleration/deceleration, electronic cam, linear & circular interpolation for multi‑axis positioning equipment.

✅ Abundant Industrial Communication Interfaces Integrated RS485, CANopen / CANlink, Ethernet Modbus‑TCP, supports multi‑device networking with VFD, HMI, servo drives.

✅ Strong Expandability Supports local & remote I/O expansion modules, analog input/output modules, flexible for system upgrade according to project requirements.

✅ Industrial‑grade Anti‑interference Hardware Optimized anti‑noise circuit for harsh workshop environment; compact size saves cabinet installation space.

✅ Easy Programming & Maintenance Complies with IEC61131‑3 standard programming language; USB & Ethernet download, real‑time monitoring & fault diagnosis, shorten commissioning period.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Main Industries

• Packaging Machinery
• Woodworking Machinery
• Textile Equipment
• Printing & Labeling Machinery
• Automatic Assembly Line
• Material Handling & Conveying
• Electronics Non‑standard Automation
• Food Processing Machinery

Typical Application Scenarios

Multi‑axis positioning platforms, servo‑driven automatic machines, high‑speed packaging equipment, sorting machines, feeding devices, engraving equipment, small production lines.

5. Packing & Logistics & Reference Market Price

• Original brand‑new unit, independent factory export carton
• Manufacturer standard warranty
• Suitable for automation warehouse stocking, FOB / DDP bulk export shipment

💰Reference Market Price Range (For Reference Only, Not Final Offer)

H3U‑2416MT:USD 150‑220 / pc Small batch(1‑5pcs): USD185‑220; Bulk order(≥10pcs): USD150‑175 Actual price depends on order quantity, stock status and shipping terms
