INOVANCE H3U Series H3U-1616MT,16 Inputs 16 Outputs Transistor

Product Title

INOVANCE H3U‑1616MT H3U Series PLC 16IN 16OUT Transistor NPN 100‑240VAC High‑speed Motion Controller

1. Product Overview

The INOVANCE H3U‑1616MT is a compact high‑performance programmable logic controller of H3U series. Equipped with 16 digital inputs and 16 NPN transistor outputs, wide‑range AC 100‑240VAC power supply; digital inputs support both NPN and PNP sensor signals. Basic instruction execution speed reaches 100ns, maximum program capacity 64K steps, 9552 data registers, built‑in 6 channels ×200kHz high‑speed pulse output. It is designed for high‑frequency motion positioning control, perfectly driving servo and stepper drives. Realizes logic sequence control, multi‑axis positioning, data acquisition and equipment interlock for small‑medium automation machinery.

2. Core Advantages & Key Features

✅ Universal AC Power & Dual‑mode Input Signal Wide AC 100‑240VAC power input; 16‑point digital input compatible with NPN / PNP sensors, flexible for on‑site wiring.

✅ NPN Transistor Output for High‑speed Motion 16‑point NPN transistor output, supports high‑frequency pulse output, specially used for servo & stepper drive control; not fit for direct driving heavy inductive loads.

✅ Ultra‑fast Processing Performance Basic instruction scan time 100ns, 64K program steps, 9552 data registers, stable operation for complex multi‑task logic.

✅ Strong Multi‑axis Motion Control Built‑in 6 × 200kHz high‑speed pulse output, supports S‑curve acceleration & deceleration, electronic cam, linear and circular interpolation function for positioning equipment.

✅ Rich Industrial Communication Interfaces Integrated RS485 Modbus‑RTU, CANopen / CANlink, Ethernet Modbus‑TCP, easy networking with VFD, HMI and servo drives.

✅ Flexible Expansion Capacity Supports local & remote I/O expansion modules, analog input/output modules, convenient for project function upgrade.

✅ Industrial‑grade Anti‑interference Hardware Optimized anti‑noise circuit for harsh factory workshop environment; compact dimension saves cabinet installation space.

✅ Easy Programming & Commissioning Complies with IEC61131‑3 standard; USB & Ethernet program download, real‑time monitoring and fault diagnosis to shorten debugging cycle.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Main Industries

• Packaging Machinery
• Woodworking Machinery
• Textile Equipment
• Printing & Labeling Machinery
• Automatic Assembly Line
• Material Handling & Conveying
• Electronics Non‑standard Automation
• Food Processing Machinery

Typical Application Scenarios

Multi‑axis positioning platforms, servo‑driven automatic machines, high‑speed packaging equipment, sorting machines, feeding devices, engraving equipment, small automated production lines.

5. Packing & Logistics & Reference Market Price

• Original brand‑new unit, independent factory export carton
• Manufacturer standard warranty
• Suitable for automation component warehouse stocking, FOB / DDP bulk export shipment
