Touchscreen LCD Human Machine Interface HMI Siemens 6AV2124-0UC24-0BX0

The 6AV2124‑0UC24‑0BX0 is TP1900 Comfort Pro industrial touch‑screen HMI, designed for expandable round‑pipe cantilever / support‑arm mounting. Operating at 24V DC, 45W, 650mA, front IP65, rear IP20 protection grade. It is responsible for on‑site parameter setup, real‑time process monitoring, trend curve display and fault alarm of automation equipment. It comes with dual‑port Ethernet integrated switch, PROFIBUS‑DP, MPI, RS422/RS485, dual‑USB2.0 and dual‑SD‑card slots, realizing reliable data communication with Siemens PLC, frequency converters and other automation spare parts. Configuration software: WinCC Comfort / Advanced. Round‑pipe extendable bracket installation, flexible position adjustment, widely used for on‑machine operating stations of large machinery.

• 18.5‑Inch Widescreen TFT Resistive Touch Display 1366×768 resolution, 16‑million‑color, dimmable LED backlight, stable touch operation even with gloves.
• Expandable Round‑Pipe Cantilever Installation Round‑pipe interface for extendable support arm, adjustable installation height and angle, break away from cabinet panel‑mount limits.
• Complete Industrial Communication Interfaces 2‑port Ethernet, RS422/RS485, MPI, PROFIBUS‑DP, dual USB2.0, dual SD‑card slot, convenient for multi‑device networking and centralized control.
• 24V DC Wide‑voltage Power Input Rated 45W, 650mA, working voltage 19.2‑28.8V DC, adapts to unstable power‑supply environment on workshop site.
• 24 MB Built‑in Project Memory Supports recipe management, historical data logging and long‑term alarm record storage for complex HMI projects.
• IP65 Front / IP20 Rear Protection Rugged aluminum housing, dust‑proof and splash‑proof front panel, suitable for ordinary industrial workshop environment.
• Built‑in Audio Speaker & Global Certifications Audible fault‑alarm reminder; Complies with CE, UL, cULus, RCM, EAC, RoHS, suitable for worldwide export orders.

• Packaging Machinery
• Automated Assembly Production Lines
• Conveyor & Material‑handling Equipment
• Water‑treatment & Environmental‑protection Systems
• Textile, Printing & Plastics Machinery
• Large‑scale General Industrial Machinery

Extendable cantilever operation terminal for large production machines, mobile operating station for packaging lines, external control panel for conveyor systems, field‑operation unit for water‑treatment facilities.

Warehouse reference scene for bulk supply: Suitable for industrial automation component warehouse stocking, export DDP bulk shipment.

• Net weight: 7.4 kg / pc
• Single carton gross weight: 8.25 kg / pc
• Original brand new, individual export carton, 12‑month manufacturer warranty.
