I. Core Specifications (Essential for Foreign Trade/Logistics)
1. Electrical Parameters
Table
Parameters
Indicators
Description
Model
ABL8RPS24400
Three-phase input
Input voltage
380–500 VAC (three-phase)
50/60Hz
Output voltage
24 V DC
Adjustable: 24–28.8V
Output current
40 A
Rated 960W
Short-time overload
150% (60A)
Sustainable for impact loads
Power factor
≥0.95 (PFC)
Low harmonics
Efficiency
Approx. 90%
Energy saving
Protection functions
Overload / Overvoltage / Undervoltage / Short circuit / Overheat
Automatic / Manual reset
Insulation withstand voltage
Input - Output: 4000V AC
Input - Ground: 3500V AC
LED indicator
Green / Orange / Red (tri-color)
Operation / Fault diagnosis
2. Machinery and Logistics (DDP/FOB Core)
Table
Parameters
Indicators
Description
Net Weight
3.8 kg
Standard Value
Packaging Weight
Approx. 4.3 kg
Including Carton/Instruction Manual
Dimensions
160 (D) × 166 (W) × 143 (H) mm
DIN Rail Mounting
Mounting Method
35mm Standard DIN Rail
Snap-on Type
Protection Rating
IP20
Rack Use
Operating Temperature
-25°C ～ +60°C
50°C No Degradation
Certifications
CE, UL 508, cCSAus, EAC, RCM, KC
Globally Applicable
3. Supply and Warranty
• Delivery Time: Regularly 6–10 weeks, some in stock
• Warranty: 18 months from the manufacturer
• Origin: Philippines
II. Core Advantages
1. 1. Three-phase wide voltage input: 380–500V AC, suitable for industrial power grids
2. High power density: 960W high current, meeting centralized power supply requirements
3. Strong overload capacity: 150% peak, suitable for motor/solenoid valve starting
4. Multiple protections: Automatic fault reset, reducing downtime
5. LED diagnostics: Quickly determine operating status
6. Stable output: High voltage accuracy, suitable for precision industrial control
III. Typical Applications
• Centralized power supply for industrial PLCs, HMIs, servos, and frequency converters
• Large-scale automated production lines, logistics sorting, and intelligent warehousing
• Building automation, data centers, and power supplies for large equipment
