Home /Products/Industrial Power Supply/Schneider ABL8RPS24030 Power Supply Input 100-500VAC 150% Overload Capacity

Schneider ABL8RPS24030 Power Supply Input 100-500VAC 150% Overload Capacity

1 pcs
MOQ
Negotiable
Price
Schneider ABL8RPS24030 Power Supply Input 100-500VAC 150% Overload Capacity
Features Gallery Product Description Chat Now
Features
Specifications
Starting Torque: 150% At 0.5 Hz
Input Voltage: 200-480 V AC
Overload Capacity: 150% For 1 Minute
Dimensions: Varies By Model
Output Frequency: 0-400 Hz
Input Frequency: 50/60 Hz
Operating Temperature Range: -10°C To 50°C
Control Method: V/F Control, Vector Control, Sensorless Vector Control
Display Type: LCD Or LED Display
Communication Protocols: Modbus, Profibus, Ethernet/IP
Harmonic Distortion: <5%
Power Rating: 0.5 KW To 500 KW
Protection Class: IP20 To IP54
Cooling Method: Forced Air Cooling
Output Voltage: 0-480 V AC
Highlight:

Schneider ABL8RPS24030

,

ABL8RPS24030 Power Supply

,

Schneider Power Supply 100-500VAC
Basic Infomation
Brand Name: Schneider
Certification: Brand new original
Model Number: ABL8RPS24030
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 1000 pcs
Product Description
Schneider ABL8RPS24030 Industrial Power Supply
High-performance 72W DIN rail power supply with wide input voltage range and comprehensive protection features for industrial automation applications.
Electrical Specifications
Parameter Specification
Input Voltage 100~120VAC / 200~500VAC (Wide Range Adaptive)
Input Frequency 50/60Hz
Output Voltage 24VDC (Fixed + Adjustable, Accuracy ±1%)
Output Current 3A (Rated), Short-Time Peak 150% (4.5A)
Output Power 72W (24V*3A)
Efficiency Typical 92% or higher
Power Factor Built-in PFC (≥0.95)
Protection Features Automatic/Manual Reset, Full protection against overvoltage, undervoltage, overcurrent, and short circuit
Insulation Withstand Voltage Input - Output: 4000VAC; Input - Ground: 3500VAC; Output - Ground: 500VAC
Output Type SELV Safety Ultra-Low Voltage (compliant with EN/IEC 60950-1)
Status Indicator Green/Red/Orange LED, displaying voltage, current, and fault status
Protection Rating IP20 (rack mounting)
Physical & Environmental Specifications
Parameter Specification
Dimensions (W×H×D) 45mm × 125mm × 125mm
Net Weight Approx. 0.3kg (0.66lb)
Gross Weight Approx. 0.78kg
Operating Temperature -25℃ to +60℃ (no derating at 60℃)
Storage Temperature -40℃ to +85℃
Humidity ≤95% RH, non-condensing
Altitude ≤3000m (derating required above this altitude)
Key Features & Certifications
  • Wide Voltage Input: 100~500VAC, globally compatible for industrial power grids in multiple regions
  • Peak Power Capability: 150% short-time overload capacity for starting inductive loads like motors and solenoid valves
  • Comprehensive Protection: Advanced fault protection with automatic/manual reset for enhanced system reliability
  • EMC Compliance: Meets EN 61000-6-1/6-2 standards with strong anti-interference for industrial environments
  • Global Certifications: CE, UL, CSA, KC, RCM, EAC, and more for worldwide market access
  • Compact Design: 45mm ultra-thin width saves cabinet space and facilitates easy installation
Typical Applications
Ideal for 24VDC power supply scenarios in industrial automation control systems, PLCs, sensors, relays, servo drives, industrial control instruments, packaging machinery, conveying equipment, machine tools, and other industrial environments. One of the most commonly used low-power DIN rail power supplies in industrial applications.
