Home /Products/Servo Systems/Siemens 6SL3210-5FE11-5UA0 Servo Drive 3 Phase 1.5kW Rated Output PROFINET Interface

Siemens 6SL3210-5FE11-5UA0 Servo Drive 3 Phase 1.5kW Rated Output PROFINET Interface

1pcs
MOQ
Negotiable
Price
Siemens 6SL3210-5FE11-5UA0 Servo Drive 3 Phase 1.5kW Rated Output PROFINET Interface
Features Gallery Product Description Chat Now
Features
Specifications
Carrier Frequency: 0.5khz-16khz
Protectionclass: IP20 To IP65
Inputvoltage: AC 110V/220V Or DC 24V/48V
Max Frequency: 500HZ
Ac Voltage: 208-230 / 240 V,220/380V,60V,AC220V
Panel Type: NO
Output Current: 0-100A
Supplier Type: ODM
Ram: 480GB
Size: 2.5
Frequency: 50/60Hz
Panel No: A5E02630230 A5E00213118/A5E02630231
Powerrating: 0.1 KW To 15 KW
Certifications: CE, RoHS
Safetyfeatures: Overcurrent, Overvoltage, Overheating Protection
Highlight:

6SL3210-5FE11-5UA0

,

Servo Drive 1.5kW

,

Servo Drive PROFINET Interface
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3210-5FE11-5UA0
Document: A700000007270949.pdf
Payment & Shipping Terms
Delivery Time: 1WEEK
Payment Terms: T/T
Supply Ability: 20PCS 1WEEK
Product Description
Parameter Name Value
General Information
Product Series SINAMICS V90
Order Number 6SL3210-5FE11-5UA0
Product Description Servo Drive, 3-phase 380-480V AC input, 1.5kW rated output, PROFINET interface, Frame Size B, IP20 protection
Product Status Active
Frame Size B
Cooling Type Natural Air Cooling
Electrical Input
Input Voltage 380-480 V AC, 3-phase
Voltage Tolerance -15% / +10%
Input Frequency 45-66 Hz
Rated Input Current 6.6 A
Control Supply Voltage 24 V DC (-15% / +20%)
Output Specifications
Output Voltage 0 – Input Voltage
Rated Output Current 5.3 A
Peak Output Current 15.9 A (300% for 3s)
Rated Output Power 1.5 kW (1.75 kW peak)
Output Frequency 0-330 Hz
Control Modes Position Control, Speed Control, Torque Control
Interfaces & I/O
PROFINET Interface 1 port (10/100 Mbps)
Digital Inputs 10 (NPN/PNP selectable)
Digital Outputs 6 (NPN)
Analog Inputs 2 (±10 V, 13-bit)
Analog Outputs 2 (±10 V, 10-bit)
Encoder Interface 1 (supports incremental encoders)
Safety Functions
Safe Torque Off (STO) Yes (PL d, Cat. 3, EN 61800-5-2)
Mechanical Data
Width 100 mm
Height 180 mm
Depth 220 mm
Weight Approx. 3.06 kg
Mounting DIN Rail or Screw Mounting
Protection Class IP20 (enclosed)
Environmental Conditions
Operating Temperature 0°C to +55°C (no derating up to 40°C)
Storage Temperature -25°C to +70°C
Relative Humidity 5% to 95% (non-condensing)
Altitude Up to 2000 m above sea level (no derating)
Standards & Approvals
CE Mark Yes
UL Certification Yes (cULus)
CSA Certification Yes
RCM (C-Tick) Yes
EAC Certification Yes
RoHS Compliance Yes
