SIEMENS 6AV6648‑0CE11‑3AX0 SIMATIC HMI SMART 1000 IE V3 10" Widescreen Touch Panel 65536 Colors
1. Product Overview
The SIEMENS 6AV6648‑0CE11‑3AX0 is SIMATIC SMART 1000 IE V3, a cost‑effective 10‑inch widescreen TFT touch HMI panel of SMART LINE series. It adopts 65536‑color high‑definition display, 1024×600 resolution, resistive touch operation. Equipped with Ethernet RJ45, RS422/485 serial port and USB host interface. Mainly designed for operator monitoring, parameter setting, alarm display, data logging & recipe management. Perfectly compatible with S7‑200 SMART, S7‑200CN, LOGO! and third‑party PLC via Modbus RTU/TCP. Widely used for small‑and‑medium automation machinery to realize human‑machine interaction between operators and control system.
2. Core Advantages & Key Features
✅ 10‑Inch Widescreen TFT Display 10.1" widescreen, 1024×600 resolution, 65536 colors, 250 cd/m² brightness, LED backlight for clear on‑site visualization.
✅ Rich Communication Interfaces Ethernet RJ45 port + RS422/485 serial port + USB Host Type‑A. Support PPI, Modbus RTU/TCP protocols, connect multiple PLC brands conveniently.
✅ Complete HMI Runtime Functions Real‑time alarm notification, historical data logging, recipe management, trend curve display, multi‑language switching for global export projects.
✅ USB Host for Convenient Maintenance USB‑A port supports USB flash drive for project upload/download, data backup, easy on‑site debugging without PC.
✅ Built‑in Real‑Time Clock RTC Onboard hardware RTC, accurate time stamp for alarms & data records.
✅ Panel Mount Installation Support horizontal & vertical cabinet panel mounting; compact front panel for standard cabinet installation.
✅ Industrial‑grade Reliability CE certified, stable performance for factory harsh workshop environment; configured by WinCC flexible SMART software.
✅ Excellent Compatibility Seamless communication with Siemens S7‑200 SMART / S7‑200CN / LOGO!, also works with third‑party automation controllers.
3. Technical Parameters
| Item |
Specification |
| Model / Order No. |
6AV6648‑0CE11‑3AX0 |
| Brand |
SIEMENS |
| Series |
SIMATIC HMI SMART LINE |
| Type |
SMART 1000 IE V3 Touch Panel |
| Display |
10.1" Widescreen TFT LCD |
| Resolution |
1024 × 600 Pixel |
| Display Colors |
65536 Colors |
| Touch Type |
4‑wire Resistive Touch Screen |
| Brightness |
250 cd/m² |
| Backlight Lifetime |
Max.20000 hours @25℃ |
| Power Supply |
DC 24V |
| Interfaces |
Ethernet(RJ45), RS422/485, USB Host Type‑A |
| Supported Protocol |
PPI, Modbus RTU, Modbus TCP |
| Function |
Alarm log, Data logging, Recipe, Trend curve, Multi‑language |
| Hardware RTC |
Built‑in Real‑Time Clock |
| Configuration Software |
WinCC flexible SMART |
| Installation |
Cabinet panel mount (Horizontal / Vertical) |
| Certification |
CE |
| Working Environment |
Standard industrial workshop ambient |
4. Application Industries & Typical Scenarios
Main Industries
- Packaging Machinery
- Water Treatment & Pump Control
- HVAC Ventilation Equipment
- Textile Machinery
- Food & Beverage Machinery
- Printing & Labeling Equipment
- Conveyor & Material Handling Equipment
- General‑purpose Non‑standard Automation
Typical Application Scenarios
Machine operation panel, production‑line monitoring system, pump & fan control station, packaging machine HMI, small assembly equipment, water treatment on‑site operator terminal.
5. Packing & Logistics & Reference Market Price
- Original brand‑new unit, original factory export carton
- Manufacturer standard 12‑month warranty
- Suitable for automation warehouse stocking, FOB / DDP bulk export shipment
