Home /Products/Human Machine Interface HMI/Proface,GP4000E,PFXGP4402WADW (GP4402WW),7" Widescreen, TFT Color LCD,800x480 (WVGA),65,536 Colors, LED

Proface,GP4000E,PFXGP4402WADW (GP4402WW),7" Widescreen, TFT Color LCD,800x480 (WVGA),65,536 Colors, LED

1pcs
MOQ
Negotiable
Price
Proface,GP4000E,PFXGP4402WADW (GP4402WW),7" Widescreen, TFT Color LCD,800x480 (WVGA),65,536 Colors, LED
Features Gallery Product Description Chat Now
Features
Specifications
Inputtype: Digital Input, Analog Input
Dimensions: Varies By Model
Power Supply: 24V DC / 110V AC / 220V AC
Inputvoltagerange: 100-240V AC
Operatingvoltage: Up To 36 KV
Control Type: Programmable Logic Controller (PLC)
Mountingtype: DIN Rail, Panel Mount
Application: Manufacturing, Process Control, Robotics
Point: 14 (8DI+6DO)
Output Typt: Relay
Safetystandardscompliance: IEC 61508, ISO 13849
Warrantyperiod: 1 To 3 Years
Operatingtemperaturerange: -20°C To 60°C
Numberofoutputs: 16 Digital Outputs
Outputtype: Digital Output, Analog Output
Highlight:

Proface GP4000E HMI 7-inch widescreen

,

GP4402WW HMI TFT color LCD

,

HMI touchscreen 800x480 WVGA display
Basic Infomation
Place of Origin: China
Brand Name: Proface
Model Number: PFXGP4402WADW
Document: RHMI_guide.pdf
Payment & Shipping Terms
Delivery Time: 1WEEK
Payment Terms: T/T
Supply Ability: 50PCS 1WEEK
Product Description

Product Specifications

Manufacturer Series Model Display Size Display Type Resolution Display Colors Backlight Type Backlight Lifetime Touch Type Touch Lifetime Input Voltage Power Consumption Interface Memory Operating Temp Storage Temp Humidity IP Rating Weight Standards
Proface GP4000E PFXGP4402WADW (GP4402WW) 7" Widescreen TFT Color LCD 800x480 (WVGA) 65,536 Colors LED 20,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 9.2 W Max RS-232C,RS-422/485,Ethernet 10/100,USB Type-A,USB mini-B Internal Flash:32MB;Backup SRAM:320KB;Variable SRAM:64KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f/NEMA4X/13;Rear:IP20 0.9 kg CE,cUL,UL,RoHS
Proface GP4000E PFXGP4502WADW (GP4502WW) 10" Widescreen TFT Color LCD 1024x600 (WXGA) 65,536 Colors LED 20,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 11.5 W Max RS-232C,RS-422/485,Ethernet 10/100,USB Type-A,USB mini-B Internal Flash:32MB;Backup SRAM:320KB;Variable SRAM:64KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f/NEMA4X/13;Rear:IP20 1.3 kg CE,cUL,UL,RoHS
Proface GP4000 PFXGP4031TAD (GP4031) 5.7" TFT Color LCD 320x240 (QVGA) 65,536 Colors LED 50,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 8.5 W Max RS-232C,RS-422/485,USB Type-A Internal Flash:16MB;Backup SRAM:320KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f;Rear:IP20 0.8 kg CE,cUL,UL,RoHS
Proface GP4000 PFXGP4501TADR (GP4501) 10.4" TFT Color LCD 640x480 (VGA) 65,536 Colors LED 50,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 12.0 W Max RS-232C,RS-422/485,Ethernet 10/100,USB Type-A,USB mini-B Internal Flash:32MB;Backup SRAM:320KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f;Rear:IP20 1.4 kg CE,cUL,UL,RoHS
Proface GP4000 PFXGP4401TAD (GP4401) 7.5" TFT Color LCD 640x480 (VGA) 65,536 Colors LED 50,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 10.5 W Max RS-232C,RS-422/485,Ethernet 10/100,USB Type-A,USB mini-B Internal Flash:32MB;Backup SRAM:320KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f;Rear:IP20 1.1 kg CE,cUL,UL,RoHS
Proface GP4000 PFXGP4601TAD (GP4601) 12.1" TFT Color LCD 800x600 (SVGA) 65,536 Colors LED 50,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 14.0 W Max RS-232C,RS-422/485,Ethernet 10/100,USB Type-A,USB mini-B Internal Flash:32MB;Backup SRAM:320KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f;Rear:IP20 1.8 kg CE,cUL,UL,RoHS
Proface GP6000 PFXGP6400TADW (GP6400) 7" Widescreen TFT Color LCD 800x480 (WVGA) 262,144 Colors LED 50,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 8.8 W Max RS-232C,RS-422/485,Ethernet 10/100,USB Type-A,USB mini-B Internal Flash:128MB eMMC;Backup NVRAM:320KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f/NEMA4X/13;Rear:IP20 0.9 kg CE,cUL,UL,RoHS
Proface GP6000 PFXGP6500TADW (GP6500) 10" Widescreen TFT Color LCD 1024x600 (WXGA) 262,144 Colors LED 50,000+ Hours Analog Resistive 1,000,000 Touches 24 VDC 11.0 W Max RS-232C,RS-422/485,Ethernet 10/100,USB Type-A,USB mini-B Internal Flash:128MB eMMC;Backup NVRAM:320KB 0 to 50°C -20 to 60°C 10-90% RH (non-condensing) Front:IP65f/NEMA4X/13;Rear:IP20 1.3 kg CE,cUL,UL,RoHS
