INOVANCE H3U‑8064MR

80DI 64DO Relay Output PLC｜AC 100‑240VAC｜NPN/PNP

1. Product Overview

The INOVANCE H3U‑8064MR belongs to H3U‑series high‑performance programmable logic controller with abundant built‑in I/O points. Equipped with 80 digital inputs and 64‑point relay outputs, supporting NPN/PNP input sensor mode. Powered by AC 100‑240VAC, it handles logic processing, high‑speed pulse acquisition, multi‑axis motion positioning, signal interlock and mass‑data collection for large‑scale automation machinery. It supports multiple industrial communication protocols for connecting HMI, servo drives and field sensors, suitable for equipment requiring plenty of switching‑signal control.

2. Core Advantages & Key Features

✅ Massive Built‑in Local I/O 80‑point digital input & 64‑point relay output; compatible with NPN / PNP sensor input; 8‑channel 200kHz high‑speed pulse input for signal capture.

✅ High‑speed Processing Performance Basic instruction execution speed 100 ns; 64 k‑steps program memory; 9552 data registers; battery‑free flash storage for program & recipe data.

✅ Rich Industrial Communication Interfaces Built‑in 100Mbps Ethernet (Modbus‑TCP), RS485 Modbus‑RTU, CANopen / CANlink field‑bus and USB programming port. Realize stable data exchange with HMI, servo and third‑party automation devices.

✅ Powerful Expandability Support local and remote extension modules, max up to 7936 remote digital I/O points, convenient for equipment function upgrade.

✅ Wide‑range AC Power Input AC 100‑240 VAC wide‑voltage power supply, adapts to unstable workshop power grid; built‑in 24VDC sensor power output.

✅ Relay Output for Heavy‑duty Scene Relay contact output, capable of driving AC/DC loads, good adaptability for general switching control.

✅ Complete Industrial‑grade Protection Over‑current, over‑voltage and short‑circuit protection, strong anti‑interference performance for cabinet installation environment.

✅ User‑friendly Programming Software Programmed by AutoShop software, supports ladder‑diagram and multiple IEC‑61131‑3 programming languages for project development, debug and maintenance.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Applicable Industries

• Packaging Machinery
• Woodworking Equipment
• Large Conveyor Production‑lines
• Textile Machinery
• Printing Equipment
• Automated Assembly Lines
• General Heavy‑duty Factory Automation

Typical Equipment

Large‑size automatic assembly machine, long conveyor control system, large packaging production‑line, wood‑working processing equipment, sorting system, custom automation machinery with massive switching I/O signals.

Image hint:PLC cabinet installation scene picture, warehouse stock picture(ECER mark for image placeholder, no actual picture file)

Warehouse reference scene for bulk supply: Suitable for industrial automation component warehouse stocking, export bulk shipment.

5. Packing & Logistics Reference

• Net weight: 2.80 kg / pc
• Single carton gross weight: 3.10 kg / pc
• Original brand new, individual export carton, 12‑month manufacturer warranty.
