INOVANCE H3U‑3232MR

INOVANCE H3U Series PLC (Programmable Logic Controller)

1. Product Overview

The INOVANCE H3U‑3232MR belongs to the H3U series high‑performance compact programmable logic controller. This main unit is configured with 32 digital inputs and 32 relay digital outputs, powered by AC 100‑240VAC. It features 100ns basic instruction processing speed and 64K‑step program memory, 9552‑word data register. Equipped with 6‑channel 200kHz high‑speed input, together with Ethernet, RS485 Modbus‑RTU, CANopen/CANlink and USB communication interfaces.

It is used to implement equipment logic sequence control, high‑speed signal acquisition, data collection and inter‑device interconnection for automated machinery. Input terminals support both NPN and PNP sensor signals, relay output is suitable for driving AC/DC actuators, contactors and solenoid valves directly. It can connect HMI, frequency converters and sensors to realize complete machine automation control, widely used in small‑to‑medium automated equipment and production lines.

2. Core Advantages & Key Features

• ✅ High‑speed Processing Performance Basic instruction execution time reaches 100ns, with large‑capacity 64K‑step program memory and 9552‑word data register, stably handles complex logic calculation tasks.
• ✅ On‑board Relay Output for General‑purpose Load 32‑point digital input compatible with NPN/PNP universal sensor signals; 32‑point relay output on CPU main unit. Relay contacts support AC250V / DC30V load, directly drive solenoid valves and contactors without intermediate relay.
• ✅ High‑speed Signal Acquisition 6‑channel 200kHz high‑speed input for encoder and pulse signal counting, supports phase‑difference counting, interrupt and pulse capture function.
• ✅ Abundant Multi‑bus Communication 100M Ethernet (Modbus‑TCP), RS485 Modbus‑RTU, CANopen / CANlink field bus, USB programming port. Convenient networking to realize centralized monitoring of multiple automation devices.
• ✅ Universal AC Power Supply AC 100‑240VAC wide‑range power input, keeps stable operation under industrial power‑grid fluctuation conditions.
• ✅ IEC 61131‑3 Standard Programming Environment Work with AutoShop programming software, support Ladder Diagram, SFC, IL programming languages, easy for program editing, debugging and parameter backup.
• ✅ Comprehensive Built‑in Protection Mechanism Over‑voltage, under‑voltage, over‑current, over‑temperature, short‑circuit and module fault diagnosis functions are integrated to improve the stability of the whole automation system.
• ✅ Flexible Expansion Potential Support local and remote I/O expansion via CAN bus, users can further expand digital and analog points according to project demands.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Applicable Industries

• Packaging & labeling machinery
• Material handling, conveyor & logistics equipment
• Textile machinery
• Wood working machinery
• Printing equipment
• Assembly automation production lines
• Water treatment & pump control system
• Special‑purpose automated machinery

Typical Equipment

Automatic assembly machines, multi‑station conveyor lines, positioning packaging machines, material feeding systems, textile looms, sorting systems, valve & contactor control cabinets.

Warehouse reference scene for bulk supply: Suitable for industrial automation component warehouse stocking, export DDP bulk shipment.

5. Packing & Logistics Reference

• Condition: Original brand‑new main unit
• Warranty: 12‑month manufacturer warranty
• Packing: Individual original export carton
• Suitable for bulk export order, DDP / FOB shipment support
