Home /Products/Human Machine Interface HMI/INOVANCE H3U Series H3U-3232MT,32 Inputs 32 Outputs Transistor, AC 100-240VAC,NPN/PNP,32,Transistor (NPN),32,100ns,64K Steps

INOVANCE H3U Series H3U-3232MT,32 Inputs 32 Outputs Transistor, AC 100-240VAC,NPN/PNP,32,Transistor (NPN),32,100ns,64K Steps

1pcs
MOQ
Negotiable
Price
INOVANCE H3U Series H3U-3232MT,32 Inputs 32 Outputs Transistor, AC 100-240VAC,NPN/PNP,32,Transistor (NPN),32,100ns,64K Steps
Features Gallery Product Description Chat Now
Features
Specifications
Mpu Points: 12 (8DI + 4DO)
Softwarecompatibility: Supports SCADA And HMI Software
Compliancestandards: CE, UL, RoHS
Actual Value: Negotiabled Price
Mounting: DIN Rail / Panel Mount
Controltype: Programmable Logic Controller (PLC)
Inputvoltagerange: 100-240V AC
Communicationprotocol: Modbus, Profibus, Ethernet/IP
Productname: Industrial Control Automation
Installationtype: Panel Mount / DIN Rail
Part No: 200-595-072-122 VM600 CPUM
Applicationindustry: Manufacturing, Process Control, Robotics
Communicationprotocols: Modbus, Profibus, Ethernet/IP, OPC UA
Type: Automation System
Output Typt: Relay
Highlight:

H3U Series PLC 32 inputs outputs

,

INOVANCE H3U transistor AC 100-240V

,

HMI PLC NPN PNP 64K steps
Basic Infomation
Place of Origin: China
Brand Name: INOVANCE
Model Number: H3U-3232MT
Document: 28fea753563c4ffcb4f96b69903...0b.pdf
Payment & Shipping Terms
Delivery Time: 1WEEK
Payment Terms: T/T
Supply Ability: 20PCS 1WEEK
Product Description
Inovance H3U Series PLC Specifications
Product Series
Inovance H3U Series PLC
Product Type
High-performance compact PLC with motion control
CPU Architecture
Integrated CPU and power supply, supports local & remote I/O expansion
Basic Instruction Cycle
100 ns/instruction
Program Memory Capacity
64 K steps
Data Memory, Auxiliary Relays (M)
9,216 points
Timers (T)
512 points
Counters (C)
256 points
Data Registers (D)
9,552 points
File Registers (R)
32,768 points
High-speed Inputs
Up to 8 channels × 200 kHz (single-phase/AB-phase counting, interrupt, pulse capture)
High-speed Outputs
Standard: 5 channels × 200 kHz; Motion: 3 channels × 500 kHz (differential)
Motion Control, Interpolation
2-axis linear/circular (standard); 3-axis linear, 2-axis circular, helical (motion)
Electronic Cam
3-axis (motion models only), 1024 points/axis
Communication Interfaces, Ethernet
1 × 100 Mbps (MODBUS TCP/IP, free port)
Serial Ports
2 × RS485/RS422 (MODBUS RTU, monitoring)
CAN
1 × CAN (CANopen DS301, CANlink)
USB
1 × USB 2.0 Full-Speed (Mini-B, programming)
Programming Languages
IEC 61131-3 compliant: LD, IL, SFC
Expansion Capability
Up to 8 local AM600 modules; remote I/O via CANlink/CANopen
Power Supply
AC 100–240 V, 50/60 Hz, 1 A
Output Load Rating
DC 30 V, 0.5 A (resistive)
Certifications
CE
Inovance H3U Series PLC Models
Model Description Supply Voltage Input Type Input Points Output Type Output Points Basic Instruction Speed Program Memory Data Memory (D) High-speed Input High-speed Output Communication Ports
H3U-1616MT 16 Inputs 16 Outputs Transistor AC 100-240VAC NPN/PNP 16 Transistor (NPN) 16 100ns 64K Steps 9552 6×200kHz 5×200kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-1616MR 16 Inputs 16 Outputs Relay AC 100-240VAC NPN/PNP 16 Relay 16 100ns 64K Steps 9552 6×200kHz - RS485×2, Ethernet×1, USB×1, CAN×1
H3U-2416MT 24 Inputs 16 Outputs Transistor AC 100-240VAC NPN/PNP 24 Transistor (NPN) 16 100ns 64K Steps 9552 6×200kHz 5×200kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-2416MR 24 Inputs 16 Outputs Relay AC 100-240VAC NPN/PNP 24 Relay 16 100ns 64K Steps 9552 6×200kHz - RS485×2, Ethernet×1, USB×1, CAN×1
H3U-3232MT 32 Inputs 32 Outputs Transistor AC 100-240VAC NPN/PNP 32 Transistor (NPN) 32 100ns 64K Steps 9552 6×200kHz 5×200kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-3232MR 32 Inputs 32 Outputs Relay AC 100-240VAC NPN/PNP 32 Relay 32 100ns 64K Steps 9552 6×200kHz - RS485×2, Ethernet×1, USB×1, CAN×1
H3U-3624MT 36 Inputs 24 Outputs Transistor AC 100-240VAC NPN/PNP 36 Transistor (NPN) 24 100ns 64K Steps 9552 6×200kHz 5×200kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-3624MR 36 Inputs 24 Outputs Relay AC 100-240VAC NPN/PNP 36 Relay 24 100ns 64K Steps 9552 6×200kHz - RS485×2, Ethernet×1, USB×1, CAN×1
H3U-4832MT 48 Inputs 32 Outputs Transistor AC 100-240VAC NPN/PNP 48 Transistor (NPN) 32 100ns 64K Steps 9552 8×200kHz 5×200kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-4832MR 48 Inputs 32 Outputs Relay AC 100-240VAC NPN/PNP 48 Relay 32 100ns 64K Steps 9552 8×200kHz - RS485×2, Ethernet×1, USB×1, CAN×1
H3U-6464MT 64 Inputs 64 Outputs Transistor AC 100-240VAC NPN/PNP 64 Transistor (NPN) 64 100ns 64K Steps 9552 8×200kHz 5×200kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-6464MR 64 Inputs 64 Outputs Relay AC 100-240VAC NPN/PNP 64 Relay 64 100ns 64K Steps 9552 8×200kHz - RS485×2, Ethernet×1, USB×1, CAN×1
H3U-8064MT 80 Inputs 64 Outputs Transistor AC 100-240VAC NPN/PNP 80 Transistor (NPN) 64 100ns 64K Steps 9552 8×200kHz 5×200kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-8064MR 80 Inputs 64 Outputs Relay AC 100-240VAC NPN/PNP 80 Relay 64 100ns 64K Steps 9552 8×200kHz - RS485×2, Ethernet×1, USB×1, CAN×1
H3U-1616MT-XP 16 Inputs 16 Outputs Transistor Motion AC 100-240VAC NPN/PNP 16 Transistor (Differential) 16 100ns 64K Steps 9552 8×200kHz 3×500kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-3232MT-XP 32 Inputs 32 Outputs Transistor Motion AC 100-240VAC NPN/PNP 32 Transistor (Differential) 32 100ns 64K Steps 9552 8×200kHz 3×500kHz RS485×2, Ethernet×1, USB×1, CAN×1
H3U-6464MT-XP 64 Inputs 64 Outputs Transistor Motion AC 100-240VAC NPN/PNP 64 Transistor (Differential) 64 100ns 64K Steps 9552 8×200kHz 3×500kHz RS485×2, Ethernet×1, USB×1, CAN×1
