INOVANCE H3U‑1616MR

Product Title

INOVANCE H3U‑1616MR H3U Series PLC 16IN 16OUT Relay Output 100‑240VAC Logic Motion Controller

The INOVANCE H3U‑1616MR belongs to H3U‑series compact high‑performance programmable logic controller. It features 16 digital inputs and 16 relay outputs, universal AC 100‑240VAC power supply, inputs support both NPN and PNP sensor signals. Basic instruction execution time reaches 100ns, maximum program capacity 64K steps, 9552 data registers, built‑in 6 channels ×200kHz high‑speed pulse output. It completes logic sequence control, data acquisition, equipment interlock and simple multi‑axis positioning for small‑medium automation machinery. Relay output design is ideal for low‑frequency switching control of solenoid valves, contactors and light‑load actuators.

2. Core Advantages & Key Features

✅ Universal AC Power & Dual‑mode Input Signal Wide AC 100‑240VAC power input; 16‑point DI compatible with NPN / PNP sensors, flexible for field‑site wiring.

✅ Reliable Relay Output 16‑point relay output, suitable for resistive & inductive loads, drives contactors, solenoid valves and other low‑frequency switching devices.

✅ High‑speed Processing Performance 100ns basic instruction speed, 64K program steps, 9552 data registers, stable execution for complex multi‑task logic.

✅ Powerful Motion Control Capacity Built‑in 6 × 200kHz high‑speed pulse output, supports positioning instruction, S‑curve acceleration & deceleration, electronic cam function.

✅ Rich Industrial Communication Integrated RS485 Modbus‑RTU, CANopen / CANlink, Ethernet Modbus‑TCP; easily networking with VFD, HMI, servo drives.

✅ Flexible Expansion Function Supports local & remote I/O expansion modules, analog input/output modules, convenient for project function upgrade.

✅ Industrial‑grade Anti‑interference Hardware Optimized anti‑noise circuit, adapts to harsh workshop environment; compact size saves cabinet installation space.

✅ Easy Programming & Commissioning Complies with IEC61131‑3 standard; supports USB/Ethernet program download, real‑time monitoring and fault diagnosis, shortens debugging cycle

3. Technical Parameters

4. Application Industries & Typical Scenarios

Main Industries

• Packaging Machinery
• Conveying & Material‑handling Equipment
• Textile Machinery
• Printing & Labeling Equipment
• Woodworking Machinery
• Food Processing Machinery
• Small Automatic Assembly Line
• General‑purpose Non‑standard Automation

Typical Application Scenarios

Packaging machines, conveyor systems, sorting equipment, feeding devices, small assembly production lines, valve & contactor control, textile looms.

5. Packing & Logistics & Reference Market Price

• Original brand‑new unit, independent factory export carton
• Manufacturer standard warranty
• Suitable for automation component warehouse stocking, FOB / DDP bulk export shipmen.
