Home /Products/Industrial Network Equipment/Siemens 6GK5004-1GM10-1AB2 SCALANCE XB004-1 LDG Unmanaged IE Switch 4x RJ45 + 1x SC (Single mode Fiber)

Siemens 6GK5004-1GM10-1AB2 SCALANCE XB004-1 LDG Unmanaged IE Switch 4x RJ45 + 1x SC (Single mode Fiber)

1pcs
MOQ
Negotiable
Price
Siemens 6GK5004-1GM10-1AB2 SCALANCE XB004-1 LDG Unmanaged IE Switch 4x RJ45 + 1x SC (Single mode Fiber)
Features Gallery Product Description Chat Now
Features
Specifications
Mounting Type: DIN Rail Or Panel Mount
Housing Material: IP40/IP67 Rated Metal Enclosure
Emi/Emc Compliance: FCC Part 15, EN 55022 Class A
Operating Temperature Range: -40°C To 85°C
Mtbf (Mean Time Between Failures): Over 1,000,000 Hours
Number Of Ports: 8 To 24
Data Transfer Rate: 10/100/1000 Mbps
Power Supply: 12-48V DC
Surge Protection: 4 KV Surge Immunity
Network Protocols Supported: Ethernet, Modbus TCP, PROFINET, EtherNet/IP
Port Types: RJ45, SFP, Fiber Optic
Redundancy Support: Yes, Ring And Mesh Topologies
Weight: Approximately 1.2 Kg
Dimensions: 150mm X 100mm X 50mm
Highlight:

Siemens SCALANCE XB004-1 unmanaged switch

,

Industrial Ethernet switch 4x RJ45

,

SCALANCE XB004-1 single mode fiber switch
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6GK5004-1GM10-1AB2
Document: 0900766b8168edbc.pdf
Payment & Shipping Terms
Delivery Time: 1WEEK
Payment Terms: T/T
Supply Ability: 20PCS 1WEEK
Product Description
Siemens SCALANCE XB004-1 LDG Unmanaged IE Switch
4x RJ45 Ports + 1x SC Single Mode Fiber Port • Gigabit Transmission (10/100/1000 Mbit/s)
Product Overview
The Siemens SCALANCE XB004-1 LDG is an unmanaged Industrial Ethernet switch designed for reliable network connectivity in industrial environments. This compact switch features 4 RJ45 copper ports and 1 SC single-mode fiber optic port, supporting Gigabit transmission speeds for high-performance applications.
Technical Specifications
Product Series SCALANCE XB004-1 LDG
Part Number 6GK5004-1GM10-1AB2
Switch Type Unmanaged Industrial Ethernet Switch
Port Configuration 4x RJ45 + 1x SC (Single Mode Fiber)
Transmission Rate 10/100/1000 Mbit/s (Gigabit)
Power Supply 24V DC (19.2~28.8V DC)
Rated Power Loss 2.5W
Dimensions (WxHxD) 45mm x 100mm x 87mm
Net Weight 0.155kg
Protection Class IP20
Mounting Type 35mm DIN Rail / Wall Mount
Operating Temperature -10°C to +60°C
Key Features
  • Gigabit fiber optic transmission for high-speed data transfer
  • Long-distance single-mode fiber support up to 10km
  • Plug & Play operation for easy installation
  • LED diagnostics for quick status monitoring
  • Compact design suitable for space-constrained industrial applications
  • Robust construction for reliable performance in industrial environments
  • DIN rail mounting for secure installation in control cabinets
Application Benefits
This industrial switch is ideal for extending network connectivity over long distances in manufacturing plants, process automation systems, and other industrial applications where reliable Gigabit Ethernet communication is required. The single-mode fiber capability ensures signal integrity over extended distances up to 10 kilometers.
