MOXA EDS-408A-MM-SC Managed Industrial Ethernet Switch 8 Port Layer 2

1pcs
MOQ
Negotiable
Price
MOXA EDS-408A-MM-SC Managed Industrial Ethernet Switch 8 Port Layer 2
Features Gallery Product Description Chat Now
Features
Specifications
Highlight:

MOXA EDS-408A-MM-SC

,

Managed Industrial Ethernet Switch

,

Industrial Ethernet Switch 8 Port
Basic Infomation
Place of Origin: Taiwan
Brand Name: MOXA
Model Number: EDS-408A-MM-SC
Document: moxa-eds-408a-series-datash...1).pdf
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 10PCS 1week
Product Description

Product Specifications

Parameter Value
Model Number EDS-408A-MM-SC
Product Name 8-Port Entry-level Managed Industrial Ethernet Switch
Product Series EDS-408A
Product Type Layer 2 Managed Ethernet Switch
Manufacturer Moxa

General Information

Hardware Function Level Standard
Fan/Fanless Fanless design
Warranty Period 5 years
MTBF 1,253,072 hours (Telcordia/GB standard)

Ethernet Interface

10/100BaseT(X) Ports (RJ45) 6 ports
Features
  • Auto-negotiation
  • full/half-duplex
  • auto MDI/MDI-X
100BaseFX Ports (Multi-mode SC connector) 2 ports
Total Ports 8
Standards Supported
  • IEEE 802.3 (10BaseT)
  • IEEE 802.3u (100BaseT(X) and 100BaseFX)
  • IEEE 802.3x (flow control)
  • IEEE 802.1D-2004 (Spanning Tree Protocol)
  • IEEE 802.1p (Class of Service)
  • IEEE 802.1Q (VLAN Tagging)
  • IEEE 802.1w (Rapid Spanning Tree Protocol)

Optical Fiber (100BaseFX Multi-mode)

Fiber Type Multi-mode (OM1, 50/125 µm)
Connector Type SC (Subscriber Connector)
Wavelength 1310 nm
TX Power Range -10 to -20 dBm
RX Sensitivity -3 to -32 dBm
Link Budget 12 dB
Dispersion Penalty 3 dB
Typical Transmission Distance 5 km

Switch Properties

IGMP Groups Support 256 groups
MAC Table Size 8K entries
Maximum VLANs 64
Packet Buffer Size 1 Mbit
Priority Queues 4
VLAN ID Range VID 1 to 4094

Software Features

Filtering
  • 802.1Q VLAN
  • GMRP
  • GVRP
  • IGMP v1/v2
  • port-based VLAN
Industrial Protocols
  • EtherNet/IP
  • Modbus TCP
Management
  • Back Pressure Flow Control
  • BOOTP/DHCP Option 66/67/82
  • DHCP Server/Client
  • IPv4/IPv6
  • LLDP
  • Port Mirroring
  • RMON (Groups 1,2,3,9)
  • SNMP v1/v2c/v3
  • Syslog
  • Telnet
  • TFTP
Redundancy Protocols
  • RSTP
  • STP
  • Turbo Ring v1/v2
  • Turbo Chain
Turbo Ring Recovery Time <20 ms @ 250 switches
Security
  • Broadcast storm protection
  • HTTPS/SSL
  • SNMPv3
  • SSH
Time Management
  • NTP Server/Client
  • SNTP

Serial Interface

Console Port RS-232 (10-pin RJ45, 115200 bps, 8 data bits, 1 stop bit, no parity)

DIP Switch Configuration

Ethernet Interface
  • Turbo Ring
  • Master
  • Coupler
  • Reserve

Input/Output Interface

Alarm Contact 1 relay output (1 A @ 24 VDC)

Power Parameters

Power Connection 1 removable 6-contact terminal block
Input Voltage 12/24/48 VDC (redundant dual inputs)
Operating Voltage Range 9.6 to 60 VDC
Input Current
  • @12 VDC: 0.61 A
  • @24 VDC: 0.30 A
  • @48 VDC: 0.16 A
Protection
  • Overload current protection
  • reverse polarity protection

Physical Characteristics

Housing Metal (IP30 rated)
Dimensions (W×H×D) 53.6 mm × 135 mm × 105 mm (2.11×5.31×4.13 in)
Weight 650 g (1.44 lb)
Mounting Options
  • DIN rail mounting
  • wall mounting (with optional kit)

Environmental Limits

Operating Temperature -10°C to 60°C (14°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Relative Humidity 5% to 95% (non-condensing)

Standards and Certifications

Safety UL 508
EMC EN 55032/35
EMI
  • CISPR 32
  • FCC Part 15B Class A
EMS IEC 61000-4-2/3/4/5/6/8
Hazardous Locations
  • ATEX
  • IECEx (Class I Division 2)
Railway EN 50121-4
Traffic Control NEMA TS2
Vibration IEC 60068-2-6
Shock IEC 60068-2-27
Freefall IEC 60068-2-31
Maritime
  • NK
  • DNV

Typical Applications

  • Industrial automation systems
  • Machine-to-machine communication
  • Factory automation
  • Transportation systems
  • Power automation
