MOXA EDS-2005-ELP 5 Port Industrial Ethernet Switch Unmanaged DIN Rail Mounting

1
MOQ
Negotiable
Price
MOXA EDS-2005-ELP 5 Port Industrial Ethernet Switch Unmanaged DIN Rail Mounting
Features Gallery Product Description Chat Now
Features
Specifications
Weight: 500 Grams
Emccompliance: EN 61000-6-2, EN 61000-6-4
Warranty: 1 Year
Dimensions: 150 X 100 X 50 Mm
Datatransferrate: 10/100/1000 Mbps
Productname: Industrial Network Equipment
Powersupply: 12-48 VDC
Mtbf: 1,000,000 Hours
Ledindicators: Power, Link/Activity, Speed
Enclosurerating: IP30
Protocolsupport: Ethernet/IP, Modbus TCP, PROFINET
Networkports: 8 X RJ45, 2 X SFP
Shockresistance: 30g, 11ms
Operatingtemperaturerange: -40°C To 75°C
Highlight:

MOXA EDS-2005-ELP

,

Industrial Ethernet Switch Unmanaged

,

5 Port Industrial Ethernet Switch
Basic Infomation
Place of Origin: China Taiwan
Brand Name: MOXA
Model Number: EDS-2005-ELP
Document: moxa-eds-2005-elp-series-da....2.pdf
Payment & Shipping Terms
Delivery Time: 5-7work days
Payment Terms: ,T/T
Supply Ability: 1-10pcs 1week
Product Description
MOXA EDS-2005-ELP 5-Port Unmanaged Industrial Ethernet Switch
A robust 5-port unmanaged industrial Ethernet switch designed for harsh environments, compliant with IEEE 802.3, IEEE 802.3u, and IEEE 802.3x standards.
General Specifications
Order Number EDS-2005-ELP
Product Series MOXA EDS-2000 Series
Product Type 5-port Unmanaged Industrial Ethernet Switch
Network Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Switching Architecture Store-and-Forward
Port Specifications
Ethernet Ports 5 x 10/100Base-T(X) RJ45 ports
Auto MDI/MDI-X Auto-sensing for all ports (no crossover cable required)
Link/Activity LEDs Per-port LED (Link/Activity, 10/100Mbps)
Transmission Distance 100m (328ft) for Cat.5e UTP/STP cable
Electrical Specifications
Power Input 12-48V DC (wide voltage range); 18-30V AC
Power Consumption Max. 3W
Power Protection Reverse polarity protection; Overvoltage protection
Surge Protection 2kV ESD (IEC 61000-4-2); 6kV surge (IEC 61000-4-5) for power ports; 2kV surge for Ethernet ports
Mechanical Specifications
Form Factor Compact DIN-rail mounting
Dimensions (W*H*D) 105 mm * 60 mm * 112 mm (4.13 in * 2.36 in * 4.41 in)
Net Weight Approx. 0.35 kg (0.77 lb)
Housing Material Metal case (anti-interference, rugged)
Protection Rating IP30 (front panel)
Mounting Method 35mm standard DIN-rail mounting
Environmental Specifications
Operating Temperature -40°C to 75°C (-40°F to 167°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Relative Humidity 5% to 95% non-condensing (no dew formation)
Vibration Resistance 5g (10-500Hz), compliant with IEC 60068-2-6
Shock Resistance 30g (11ms half-sine), compliant with IEC 60068-2-27
Altitude Rating 0 to 5000m (16404ft) without derating
EMC Compliance
EMI EN 55032 Class A, FCC Part 15 Class A, VCCI Class A
EMS EN 55034, IEC 61000-4-2/3/4/5/6/8
Key Functional Features
  • Switching Capacity: 1Gbps (non-blocking)
  • Forwarding Rate: 0.744 Mpps (wire-speed forwarding)
  • MAC Address Table: 2K entries (auto-learning, auto-aging)
  • Flow Control: Full-duplex: IEEE 802.3x pause frame; Half-duplex: Backpressure
  • Industrial Reliability: No fan (passive cooling), no moving parts
  • Operation: Plug-and-Play (unmanaged, no configuration required)
Industrial-Grade Reliability: Designed for harsh industrial environments with wide temperature range, robust surge protection, and rugged metal housing for maximum durability and performance.
