Home /Products/Human Machine Interface HMI/Siemens 6AV2124-0MC24-1AX0 TP1200 Comfort INOX 12.1 inches PROFINET、PROFIBUS DP/MPI、USB、SD card

Siemens 6AV2124-0MC24-1AX0 TP1200 Comfort INOX 12.1 inches PROFINET、PROFIBUS DP/MPI、USB、SD card

1pcs
MOQ
Negotiable
Price
Siemens 6AV2124-0MC24-1AX0 TP1200 Comfort INOX 12.1 inches PROFINET、PROFIBUS DP/MPI、USB、SD card
Features Gallery Product Description Chat Now
Features
Specifications
Interface: RS422, RS232, Ethernet, USB And SD Card
Application: Industrial Automation Control
Screensize: 7 Inches
Displaytype: Touchscreen LCD
Powersupply: 24V DC
Memory: 128MB RAM, 256MB Flash
Inputmethod: Touchscreen, Physical Buttons
Operatingtemperature: -10°C To 60°C
Display Type: TFT Colour LCD
Dimensions: 190mm X 140mm X 40mm
Size: 7″
Resolution: 800 X 480 Pixels
Productname: Human Machine Interface (HMI)
Mountingtype: Panel Mount
Operatingsystem: Embedded Linux
Highlight:

Siemens TP1200 HMI touch panel

,

12.1 inch INOX HMI display

,

PROFINET PROFIBUS DP HMI
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6AV2124-0MC24-1AX0
Document: hmi_comfort_panels_pro_oper...HS.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Siemens TP1200 Comfort INOX HMI Panel
12.1-inch industrial HMI panel with PROFINET, PROFIBUS DP/MPI, USB, and SD card interfaces, designed for demanding environments with INOX stainless steel construction.
Product Specifications Comparison
Property TP1200 Comfort TP1200 Comfort INOX
Product Series TP1200 Comfort TP1200 Comfort INOX
Model Number 6AV2124-0MC01-0AX0 6AV2144-8MC20-0AA0
Display Size 12.1" Widescreen 12.1" Widescreen
Display Type TFT TFT
Resolution 1280 x 800 1280 x 800
Colors 16 Million 16 Million
Touch Type Capacitive Multi-touch Capacitive Multi-touch
Interfaces 2x PROFINET (RJ45), 1x PROFIBUS DP/MPI (RS485), 2x USB Host, 1x USB Device, 1x SD Card Slot 2x PROFINET (RJ45), 1x PROFIBUS DP/MPI (RS485), 2x USB Host, 1x USB Device, 1x SD Card Slot
Protection Rating Front IP65, Rear IP20 Front IP69K, Rear IP20
Installation Panel Mount Stainless Steel Panel Mount
Power Supply 24 V DC ±10% 24 V DC ±10%
Power Consumption Max. 25 W Max. 28 W
Operating Temperature 0 °C ~ +50 °C 0 °C ~ +50 °C
Storage Temperature -20 °C ~ +60 °C -20 °C ~ +60 °C
Dimensions (WxHxD) 310 mm x 238 mm x 60 mm 310 mm x 238 mm x 62 mm
Weight Approx. 1.7 kg Approx. 1.9 kg
Memory 12 MB Configuration Memory 12 MB Configuration Memory
Software WinCC Comfort (TIA Portal) WinCC Comfort V15+
Certifications CE, UL, CSA, KEMA, ATEX CE, UL, CSA, KEMA, ATEX, Hygiene
Key Features Overview
  • Product Series: TP1200 Comfort / TP1200 Comfort INOX
  • Display Size: 12.1-inch widescreen TFT display
  • Resolution: 1280×800 pixels with 16 million colors
  • Touch Interface: Capacitive multi-touch technology
  • Industrial Interfaces: PROFINET, PROFIBUS DP/MPI, USB, and SD card
  • Protection Rating: Front panel IP65/IP69K with rear panel IP20
  • Installation: Panel mount with stainless steel construction (INOX model)
  • Power Supply: 24V DC ±10% operation
  • Operating Range: 0°C to +50°C operating temperature
  • Configuration Memory: 12MB for project storage
  • Software Compatibility: WinCC Comfort with TIA Portal integration
Tag:

Panel Mount HMI

HMI Human Machine Interface

Siemens SIMATIC HMI
