Home /Products/Human Machine Interface HMI/Siemens 6AV2124-0MC24-0BX0 TP1200 Comfort INOX 12.1 inches PROFINET、PROFIBUS DP/MPI、USB、SD card

Siemens 6AV2124-0MC24-0BX0 TP1200 Comfort INOX 12.1 inches PROFINET、PROFIBUS DP/MPI、USB、SD card

1pcs
MOQ
Negotiable
Price
Siemens 6AV2124-0MC24-0BX0 TP1200 Comfort INOX 12.1 inches PROFINET、PROFIBUS DP/MPI、USB、SD card
Features Gallery Product Description Chat Now
Features
Specifications
Powersupply: 24V DC
Operatingtemperature: -20°C To 60°C
Display Type: TFT Colour LCD
Mountingtype: Panel Mount
Screensize: 7 Inches
Weight: 500 Grams
Inputmethod: Touch
Size: 10″
Dimensions: 190mm X 140mm X 45mm
Interface: RS422, RS232, Ethernet, USB And SD Card
Productname: Human Machine Interface (HMI)
Displaytype: Touchscreen LCD
Operatingsystem: Embedded Linux
Storagetemperature: -30°C To 70°C
Memory: 128 MB RAM, 256 MB Flash
Highlight:

Siemens TP1200 Comfort HMI 12.1 inches

,

INOX HMI with PROFINET PROFIBUS

,

TP1200 Comfort touch panel with USB
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6AV2124-0MC24-0BX0
Document: hmi_comfort_panels_pro_oper...HS.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Siemens TP1200 Comfort INOX HMI Panel
The Siemens 6AV2124-0MC24-0BX0 TP1200 Comfort INOX is a 12.1-inch HMI panel designed for demanding industrial environments with enhanced protection ratings and stainless steel construction.
Technical Specifications Comparison
Property TP1200 Comfort TP1200 Comfort INOX
Product Series TP1200 Comfort TP1200 Comfort INOX
Model Number 6AV2124-0MC01-0AX0 6AV2144-8MC20-0AA0
Display Size 12.1" Widescreen 12.1" Widescreen
Display Type TFT TFT
Resolution 1280 x 800 1280 x 800
Colors 16 Million 16 Million
Touch Type Capacitive Multi-touch Capacitive Multi-touch
Interfaces 2x PROFINET (RJ45), 1x PROFIBUS DP/MPI (RS485), 2x USB Host, 1x USB Device, 1x SD Card Slot 2x PROFINET (RJ45), 1x PROFIBUS DP/MPI (RS485), 2x USB Host, 1x USB Device, 1x SD Card Slot
Protection Rating Front IP65, Rear IP20 Front IP69K, Rear IP20
Installation Panel Mount Stainless Steel Panel Mount
Power Supply 24 V DC ±10% 24 V DC ±10%
Power Consumption Max. 25 W Max. 28 W
Operating Temperature 0 °C ~ +50 °C 0 °C ~ +50 °C
Storage Temperature -20 °C ~ +60 °C -20 °C ~ +60 °C
Dimensions (WxHxD) 310 mm x 238 mm x 60 mm 310 mm x 238 mm x 62 mm
Weight Approx. 1.7 kg Approx. 1.9 kg
Memory 12 MB Configuration Memory 12 MB Configuration Memory
Software WinCC Comfort (TIA Portal) WinCC Comfort V15+
Certifications CE, UL, CSA, KEMA, ATEX CE, UL, CSA, KEMA, ATEX, Hygiene
Key Features
  • Product Series: TP1200 Comfort / TP1200 Comfort INOX
  • Model Number: Core model configuration
  • Display Size: 12.1-inch wide screen TFT display
  • Resolution: 1280×800 pixels with 16 million colors
  • Touch Type: Capacitive multi-touch technology
  • Interfaces: PROFINET, PROFIBUS DP/MPI, USB, SD card connectivity
  • Protection Rating: Front panel IP65/IP69K; Back panel IP20
  • Installation: Panel installation with stainless steel construction
  • Power Supply: 24V DC ±10% operation
  • Operating Temperature: 0°C to +50°C range
  • Storage Temperature: -20°C to +60°C range
  • Weight: Approximately 1.7-1.9kg
  • Memory: 12MB configuration memory
  • Software: WinCC Comfort with TIA Portal integration
The TP1200 Comfort INOX variant features enhanced IP69K front protection and stainless steel construction, making it ideal for harsh industrial environments requiring high-pressure washdown and hygienic conditions.
Tag:

Panel Mount HMI

HMI Human Machine Interface

Siemens SIMATIC HMI
