MOOG SM2301D Servo Motor with 4.0 kW Rated Output Power, 24 VDC Holding Brake, and Hall Sensor Feedback

1 pcs
MOQ
Negotiable
Price
MOOG SM2301D Servo Motor with 4.0 kW Rated Output Power, 24 VDC Holding Brake, and Hall Sensor Feedback
Features Gallery Product Description Chat Now
Features
Specifications
Warranty: 90 Days
Rated Output Power: 4.0 KW
Stock Location: China
Durability: Strong
Maximum Operating Voltage: 325v
Brake: 24 VDC Holding Brake
Feedback: Hall Sensor
Stock: Rich
User: Students,Engineers Etc.
Thermal Time Constant: 150s
Stepper Motor: 4 Wire Stepper Motor
Maximum Current: 10A
Ram: 2GB
Rated Time: Continuous
Productgroup Id: 4,6
Highlight:

4.0 kW Rated Output Power Servo Motor

,

24 VDC Holding Brake Stepper Motor

,

Hall Sensor Feedback MOOG SM2301D
Basic Infomation
Brand Name: MOOG
Certification: Brand new original
Model Number: SM2301D
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
MOOG SM2301D Servo Motor
High-performance NEMA 23 standard servo motor designed for precision industrial applications.
Core Technical Parameters
Parameter Value
Holding Torque 0.87 N・m (approx. 123 oz-in)
Number of Phases / Step Angle 2 phases, 1.8° (full step), 0.9° (half step)
Phase Resistance 0.43 Ω ± 10%
Phase Inductance 1.3 mH ± 20%
Insulation Withstand Voltage 500 VAC
Insulation Class B
Weight Approx. 0.46 kg
Operating Temperature -20°C ～ +50°C (non-condensing)
Shaft Diameter 8 mm Single output shaft (standard); optional double output shaft (model suffix -[2])
Mechanical and Installation Specifications
  • Flange Size: 57 × 57 mm (NEMA 23 standard hole spacing)
  • Shaft Load: Radial load recommended ≤ 15 N, axial load ≤ 5 N
  • Cable Configuration: Rear straight cable, standard cable length
  • Custom Options: Aviation plugs available upon request
  • Protection Rating: IP40 (dustproof, not waterproof, suitable for cabinet installation)
Model Verification Note
Important: This model (SM2301D) is frequently confused with Moog Animatics model SM2310D. The SM2310D is a Class 4 Legend series NEMA23 closed-loop servo all-in-one unit with D-Style connector, operating at 48VDC. It features integrated motor, controller, encoder, and amplifier with significantly different rated torque/speed specifications and a higher price point compared to the stepper motor SM2301D.
