MITSUBISHI MR-J5-200A Compatible with CC-Link IE TSN, EtherCAT, SSCNET III/H, and general-purpose interface

1
MOQ
Negotiable
Price
MITSUBISHI MR-J5-200A Compatible with CC-Link IE TSN, EtherCAT, SSCNET III/H, and general-purpose interface
Features Gallery Product Description Chat Now
Features
Specifications
Power Rating: 2000W
Dimensions: 200mm X 100mm X 150mm
Model: SSDSC2KG480G801
Feedback Type: Encoder, Resolver, Hall Sensors
Conditions: 100% Original
Application: Industrial Application
Payment Term: TT.Paypal.Western Union.Moneygram
Protectionclass: IP20
Payment: T/T/Paypal/Western Union/Money Gram
Series: D3-S4610
Control Type: FVC
Communicationinterface: EtherCAT/Modbus/RS485
Certifications: CE, RoHS
Communication Protocol: CANopen, EtherCAT, Modbus
Controlmode: Position/Speed/Torque
Highlight:

Mitsubishi MR-J5-200A servo drive

,

CC-Link IE TSN servo drive

,

EtherCAT compatible servo drive
Basic Infomation
Place of Origin: china
Brand Name: MITSUBISHI
Model Number: MR-J5-200A
Document: sv2006-5c.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description

MITSUBISHI MR-J5-200A

is a 200V general-purpose servo amplifier in the MELSERVO-J5 series of Mitsubishi Electric. It is designed for 2kW (2000W) medium-power precise control, compatible with incremental encoder motors, and offers both high-speed response and stable reliability.

Model Meaning
MR-J5:

Fifth-generation MELSERVO servo system;

200:

Corresponds to the rated output of 2kW;

A:

Compatible with single-phase / three-phase AC 200–240V, supports incremental encoder motors, and is a low-voltage general pulse type.

Core Specifications
Power Supply and Output
  • Main Circuit: Single-phase / three-phase AC 200–240V (50/60Hz), also supports DC 283–340V; Control Circuit DC 24V ± 10% (0.5A).
  • Rated Power 2kW, Rated Output Current 11.0A, 3 times overload (approximately 33A peak), compatible with medium-power short-term impact loads.
Control Performance
  • Speed Loop Bandwidth 2.5kHz, significant improvement in dynamic response; Supports seamless switching between position, speed, and torque modes.
  • 0.3-second rapid self-tuning + mechanical resonance suppression, servo ON automatically optimizes; Pulse Command Maximum 4M pulses/s.
  • Compatible with 17-bit incremental encoders (131072 p/rev), high positioning accuracy, smooth low-speed operation.
Safety and Diagnosis
  • Standard STO (Safety Torque Shutdown), compliant with PLd/SIL2; Includes full protection against overcurrent / overvoltage / undervoltage / overheating / encoder abnormalities.
  • Mechanical Diagnosis Function (ball screw, belt, gear), supports predictive maintenance.
Physical and Environmental
  • IP20 protection, suitable for installation in control cabinets; Operating Temperature 0–+60℃; Compact size, easy for dense arrangement.
Interfaces and Debugging
  • Pulse Command (open collector / differential), Analog I/O, STO Safety Terminal; Built-in USB and RS-485, supports MR Configurator3 software tuning, monitoring, and alarm query.
Compatibility and Applications
  • Compatible Motors: HG-KR23B, HG-SR202, etc. 2kW incremental servo motors.
  • Typical Applications: CNC machine feed axis, automated handling mechanism, packaging machinery, electronic assembly line, etc. for medium-power precise positioning scenarios.
