Siemens 6AV2124-0QC02-0AX0 SIMATIC HMI TP1500 Comfort Panel (Spare Part)

1pcs
MOQ
Negotiable
Price
Siemens 6AV2124-0QC02-0AX0 SIMATIC HMI TP1500 Comfort Panel (Spare Part)
Features Gallery Product Description Chat Now
Features
Specifications
Output Points: 20
Programming_Language: Ladder Logic, Function Block Diagram
Dimensions: 100mm X 75mm X 60mm
Power Supply Voltage: AC240-360V.
Operating_Temperature_Range: -20°C To 60°C
Model: S7-1200
Weight: 0.5 Kg
Color: Normal
Communication_Protocols: Ethernet, Profibus, Modbus
Condition: New Original With Sealed
CPU_Speed: 100 MHz
Part No: Z-16TD2
Points: 40 (24DI+16DO)
Output_Type: Digital And Analog
Actual Price: Based On Offer
Highlight:

Siemens SIMATIC HMI TP1500 Comfort Panel

,

HMI TP1500 spare part

,

SIMATIC HMI touch panel
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6AV2124-0QC02-0AX0
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 10PCS 1week
Product Description
Siemens 6AV2124-0QC02-0AX0 SIMATIC HMI TP1500 Comfort Panel (Spare Part)
Product Overview

The Siemens SIMATIC HMI TP1500 Comfort Panel is a high-performance industrial touch panel designed for demanding automation applications. This spare part replacement offers reliable operation with advanced display technology and robust communication interfaces.

Technical Specifications
Parameter Value
Part Number 6AV2124-0QC02-0AX0
Manufacturer Siemens
Display Type TFT widescreen
Screen Diagonal 15.4 inches
Display Resolution 1280 (H) × 800 (V) pixels
Number of Colors 16,777,216 (16 million)
Touch Operation Yes
Backlighting MTBF 80,000 hours
Operating System Windows CE 6.0
Processor X86
Configuration Memory 24 MB
Communication Interfaces PROFINET (IRT), PROFIBUS DP, MPI
Power Supply 24 V DC
Current Consumption 1.5 A
Active Power Input 36 W
Dimensions (W × H × D) 415 mm × 310 mm × 75 mm
Mounting Cutout (W × H) 396 mm × 291 mm
Mounting Position Vertical
Protection Rating IP65 (front), IP20 (rear)
Operating Temperature 0 to 50 °C
Storage/Transport Temperature -20 to 60 °C
Maximum Relative Humidity 90% (non-condensing)
Weight (without packaging) 4.4 kg
Material Aluminum
Key Features
  • High-resolution 15.4-inch TFT widescreen display with 16 million colors
  • Multi-touch operation for intuitive control
  • Long-life backlighting with 80,000 hours MTBF
  • Robust industrial communication via PROFINET, PROFIBUS, and MPI
  • IP65 front protection for harsh industrial environments
  • Aluminum construction for durability
  • Compatible with WinCC Comfort V11 SP2 and higher
Certifications & Compatibility

Certifications: CE Certified, cULus Listed, KC/RCM Approved

Software Compatibility: WinCC Comfort V11 SP2 and higher

Successor Model: 6AV2124-0QC02-0AX1

Product Codes: EAN 4025515081210 | UPC 040892952407
