Pepperl+Fuchs UC4000-30GM-IUR2-V15 Ultrasonic Sensor with 200-4000 mm Detection Range, Dual Analog Output, and IP65 Protection

1 pcs
MOQ
888 USD
Price
Pepperl+Fuchs UC4000-30GM-IUR2-V15 Ultrasonic Sensor with 200-4000 mm Detection Range, Dual Analog Output, and IP65 Protection
Features Gallery Product Description Chat Now
Features
Specifications
Highlight:

200-4000 mm Detection Range Ultrasonic Sensor

,

IP65 Protection Ultrasonic Sensor

,

Dual Analog Output Ultrasonic Sensor
Basic Infomation
Brand Name: PEPPERL+FUCHS
Model Number: UC4000-30GM-IUR2-V15
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 1000 pcs
Product Description
Pepperl+Fuchs UC4000-30GM-IUR2-V15 Ultrasonic Sensor
Technical Specifications
Brand and Model Pepperl+Fuchs (P+F) UC4000-30GM-IUR2-V15
Detection Range 200-4000 mm (Blind Zone 0-200 mm)
Power Supply 10-30 V DC
Output 4-20 mA + 0-10 V Dual Analog Input
Interfaces 5-pin M12, RS232 (9600 baud rate)
Weight 210 g
Protection Rating IP65
Thread M30×1.5
Key Features
  • Single-head design with compact structure for easy installation
  • Adjustable sound power and sensitivity for different working conditions
  • LED Status Indicators: Green (Power/Detection), Yellow (Range), Red (Fault)
  • Built-in temperature compensation with teach-programming support
  • Bidirectional synchronization function prevents interference from multiple sensors
  • Compatible with ULTRA 3000 software for parameterized configuration
  • Resistant to dust and humid environments
Advanced Capabilities
This ultrasonic sensor is ideal for liquid level, material level, and distance detection applications. The robust design ensures reliable performance in challenging industrial environments.
Typical Applications
Warehousing / Logistics
Material level, stacking height, and distance measurement
Packaging/Printing
Roll material tension and positioning control
Food/Chemical
Non-contact liquid level monitoring
Automotive/Metal
Workpiece positioning and collision avoidance
