1. Core Parameters (Accurately Adapted for Quotation/Logistics/Customs Clearance)
- Weight: Net weight per unit approximately 0.062 kg; Gross weight per unit including packaging approximately 0.074 kg (Bulk packaging: 44 units/box approximately 3.711 kg, calculated for cross-border logistics)
- Product Type: Inductive proximity switch, based on high-frequency oscillation principle, detects only metal objects, strong anti-interference capability, suitable for harsh industrial environments.
- Structural Specifications: Cylindrical design, M18×1 thread, 74mm length, flush mounting possible, equipped with an M12 four-pin male connector for convenient wiring, can be directly mounted on a flat surface or bracket.
- Detection Parameters: Detection distance 8mm (effective detection range 4~8mm), response frequency ≤1000Hz, response delay 0.3ms, reset delay 0.7ms, accurate detection, rapid response.
- Electrical Specifications: Power supply voltage 12~48VDC (with reverse polarity protection), 3-wire NPN output, 1 NO (normally open) contact, output current ≤200mA (with overload and short circuit protection), voltage drop <2V (closed state), no-load current ≤10mA.
- Protection Rating: IP67 (dustproof and waterproof), IP69K (high-pressure spray resistant), compliant with IEC 60529 and DIN 40050 standards, capable of withstanding workshop oil, dust, and high-pressure water jets, suitable for outdoor and harsh industrial environments.
- Material and Manufacturing Process: The housing is made of nickel-plated brass, and the detection surface is made of PPS material, which is wear-resistant, corrosion-resistant, and has a robust structure, suitable for complex industrial conditions.
- Environmental Adaptability: Operating temperature -25℃~+70℃, storage temperature -40℃~+85℃; shock resistance 50gn/11ms, vibration resistance 25gn (amplitude ±2mm, 10-55Hz), strong stability, suitable for mobile devices and high-frequency vibration scenarios.
- Certification Standards: CE, UL, CSA certified, compliant with IEC 60947-5-2 standard, materials comply with RoHS and REACH requirements, meeting import compliance needs of multiple countries and suitable for global industrial scenarios.
- Export Information: ❌ No built-in battery, no supercapacitor, no lithium battery; ❌ Not a dangerous good, exported as general cargo, no logistics compliance risks; individual product packaging dimensions 4.5cm×9.5cm×7cm, convenient for bulk transportation.
2. Product Features (Sales Script/Details Page Highlights)
- Detection Advantages: Non-contact detection, no mechanical wear, avoids collision with the object being measured, long mechanical life, adaptable to high-frequency detection scenarios, detection frequency up to 1000Hz, meeting the high-frequency counting requirements of automated production lines.
- Installation Advantages: M18 thread design with double nuts, can be directly installed on a flat surface or bracket, flush installation is suitable for narrow installation spaces, M12 plug wiring is convenient, greatly improving installation efficiency and reducing labor costs.
- Protection Advantages: IP67+IP69K dual protection, dustproof, waterproof, and high-pressure spray resistant, adaptable to harsh industrial environments such as dusty, humid, and high-pressure cleaning, reducing equipment maintenance costs and extending service life.
- Performance Advantages: Triple protection with reverse polarity, overload, and short circuit, strong anti-interference capability, avoiding equipment damage from circuit failures; rapid response, accurate detection, effectively avoiding false triggering, ensuring stable operation of automated production lines.
- Universal Compatibility: Widely used in machine tools, automated production lines, conveying equipment, lifting machinery, packaging machinery, mobile equipment, and other fields, it can realize functions such as position detection, counting, limit switching, and positioning of metal objects, with extremely high versatility.
- Compliance Advantages: Original and genuine products, complete certifications, conforming to international industrial standards, with no compliance risks for export; compact structure, high cost performance, stable stock availability, easy to prepare and transport, suitable for bulk purchasing needs.
