Schneider XCE103C Steel Roller Plunger Vertical Limit Switch 1NO 1NC IP65 Spring Return Industrial Travel Switch

1 pcs
MOQ
88 USD
Price
Schneider XCE103C Steel Roller Plunger Vertical Limit Switch 1NO 1NC IP65 Spring Return Industrial Travel Switch
Features Gallery Product Description Chat Now
Features
Specifications
Protectionrating: IP65
Mountingtype: Panel/Surface Mount
Body Material: Die-cast Aluminum/Plastic
Weigth: Approx.22g
Installation: Flush / Non-flush
Operating Force: 0.5N To 5N
Certifications: CE, UL, RoHS
Application: Position Detection, Safety Interlock
Ip Grand: IP68
Indicator: LED
Standardscompliance: IEC, UL, CE
Voltage: AC220V
Mechanical Life: 1,000,000 Cycles
Ip Protaction: IP65
Operatingforce: 0.5N To 5N
Electricalrating: Typically 10A At 250VAC
Current Rating: 100mA To 300mA
Mounting Type: Panel/Surface Mount
Operating Temperature: -25°C To 85°C
Standard Cable: 1.1m
Contact Resistance: ＜15mΩ
Protection Rating: IP67 / IP68
Aluminum: Grey And Nature Color
Output Type: PNP / NPN / NO / NC
Switching Frequency: Up To 10kHz
Lever: Stainless Steel 304
Ingressprotection: IP65
Contactor: Silver And Gold
Ambient Temperature: -40℃~70℃; ＜95%RH
Weight: Approx.92g
Insulation Resistance: ＞100MΩ（＜500VDC）
Type: Mechanical/Electrical
Operating Frequency: Max 30 Operations/min
Enclosurerating: IP65
Contactmaterial: Silver Alloy
Switching Current: 5A
Operating Ambient: -5℃~+65℃; ＜95%RH
Highlight:

Schneider vertical limit switch

,

Steel roller plunger limit switch

,

IP65 industrial travel switch
Basic Infomation
Brand Name: Schneider
Model Number: XCE103C
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Core Parameters
Weight: Net weight 0.164 kg; approx. 0.20 kg including packaging
Actuating Head: φ3mm steel round bar rocker, spring automatic return, bidirectional side trigger
Contacts: 1 NO + 1 NC (1C/O, snap action)
AC-15: 240V / 3A; DC-13: 220V / 0.3A
Lifespan: Electrical 800,000 cycles; Mechanical 10,000,000 cycles
Protection: IP65 (dustproof and waterproof)
Operating Temperature: -25°C ~ +70°C; Storage: -40°C ~ +70°C
Wiring: Screw terminal 1*1.5mm²; Cable entry 6–9mm
Trigger: Bidirectional side trigger, maximum trigger force 6–7.5N, reset force ≥0.5N
Dimensions: Width 28mm, Height 128mm, Depth 43mm
Electrified/ With battery: ❌ Without battery, non-hazardous goods
Product Features
  • Metal + plastic structure, vibration resistant and durable, suitable for medium-level industrial scenarios
  • φ3mm steel round bar rocker arm, precise action, wear resistant
  • Bidirectional side triggering, flexible installation, adaptable to various machine workstations
  • IP65 protection, reliable in workshops, outdoors, and humid and dusty environments
  • Commonly used in: machine tools, conveyor lines, packaging machinery, lifting equipment, automated production lines
