MITSUBISHI FR-F840-04320-2-60 Inverter; Rated Power: 185-220kW; 3x380-500V

1
MOQ
Negotiable
Price
MITSUBISHI FR-F840-04320-2-60 Inverter; Rated Power: 185-220kW; 3x380-500V
Features Gallery Product Description Chat Now
Features
Specifications
Connectivity: Wi-Fi, Ethernet, Serial
Mounting Type: Wall-mounted Or Panel-mounted
Ambient Temperature Range: -10°C To 50°C
Environmentalrating: IP20 To IP65 Depending On Enclosure
Dimensions: Varies By Power Rating And Manufacturer
Humidity Range: 0-95% Non-condensing
Frequencyrange: 0 To 400 Hz Or Higher
Safetyfeatures: Built-in Diagnostics And Fault Detection
Outputfrequencyrange: 0 To 400 Hz
Operatingtemperature: -20°C To 60°C
Power Supply Voltage: 100 – 240VAC.
Controlmethod: V/F Control, Vector Control, Direct Torque Control
Communication Protocols: Modbus, Profibus, Ethernet/IP
Processortype: Microprocessor-based
Output Frequency: 0-400 Hz
Highlight:

Mitsubishi FR-F840 VFD inverter

,

185-220kW variable frequency drive

,

380-500V industrial motor controller
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-F840-04320-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
FA-Inverter: Inverter
Series FR-F800 SERIES
Type FR-F800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 432
Rated Output Current LD (A) 361
Rated Motor Capacity SLD (kW) 220
Rated Motor Capacity LD (kW) 185
Frequency Range (Hz) 0,2–590
Control Method V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
USB 1+1 MINI
Ethernet Port 1
Built-In Network CC-LINK IE FIELD NETWORK BASIC, iQSS, SLMP, MELSOFT/FA, MODBUS/TCP, BACNET/IP
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 4650
Power Loss LD (W) 3800
Standby Power Consumption (W) 96
Protection Class IP00
Conformity
CE COMPLIANT
UL/cUL COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals DNV,ABS
UKCA COMPLIANT
Product Dimensions & Weight
Width (mm) 498
Height (mm) 1010
Depth (mm) 380
Weight (kg) 117
Life Cycle
Predecessor 156608
Serial No. on the Box QR1
Campaigns
Selling Status Standard
Product Packaging
Cardboard (g) 13122
Other paper (g) 0
Aluminum (g) 0
Steel (g) 0
Styrofoam (g) 0
Other plastic (g) 495
Wood (g) 0
Glass (g) 0
Others (g) 0
