MITSUBISHI FR-F840-03610-2-60 Inverter; Rated Power: 160-185kW; 3x380-500V

1
MOQ
Negotiable
Price
MITSUBISHI FR-F840-03610-2-60 Inverter; Rated Power: 160-185kW; 3x380-500V
Features Gallery Product Description Chat Now
Features
Specifications
Bypass Function: Manual/Automatic Bypass Available
Humidityrange: 5% To 95% Non-condensing
Displaytype: LCD Or LED Display For Status And Parameter Settings
Model: CPM2A-60CDR-A
Mpu Points: 12 (8DI + 4DO)
Storage Temperature Range: -40°C To 85°C
Harmonic Distortion: <5%
Humidity Range: 0-95% Non-condensing
Communicationprotocol: Modbus, Profibus, Ethernet/IP
Memorycapacity: Typically 16KB To 1MB
Output Typt: Relay
Responsetime: Milliseconds
Input Frequency: 50/60 Hz
Outputfrequency: 0 To 400 Hz Or Higher
Output Method: Transistor
Highlight:

Mitsubishi FR-F840 VFD inverter

,

160-185kW variable frequency drive

,

3x380-500V industrial VFD
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-F840-03610-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
FA-Inverter: Inverter
Series FR-F800 SERIES
Type FR-F800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 361
Rated Output Current LD (A) 325
Rated Motor Capacity SLD (kW) 185
Rated Motor Capacity LD (kW) 160
Frequency Range (Hz) 0,2–590
Control Method V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
USB 1+1 MINI
Ethernet Port 1
Built-In Network CC-LINK IE FIELD NETWORK BASIC, iQSS, SLMP, MELSOFT/FA, MODBUS/TCP, BACNET/IP
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 4050
Power Loss LD (W) 3600
Standby Power Consumption (W) 78
Protection Class IP00
Conformity
CE COMPLIANT
UL/cUL COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals DNV,ABS
UKCA COMPLIANT
Product Dimensions & Weight
Width (mm) 465
Height (mm) 740
Depth (mm) 360
Weight (kg) 78
Life Cycle
Predecessor 156607
Serial No. on the Box QR1
Campaigns
Selling Status Standard
Product Packaging
Cardboard (g) 7666
Other paper (g) 0
Aluminum (g) 0
Steel (g) 0
Styrofoam (g) 0
Other plastic (g) 215
Wood (g) 0
Glass (g) 0
Others (g) 0
