MITSUBISHI FR-F840-02600-2-60 Inverter; Rated Power: 110-132kW; 3x380-500V

1
MOQ
Negotiable
Price
MITSUBISHI FR-F840-02600-2-60 Inverter; Rated Power: 110-132kW; 3x380-500V
Features Gallery Product Description Chat Now
Features
Specifications
Efficiency: Up To 98%
Outputvoltage: Variable, Up To Input Voltage
Dimensions: 90mm X 60mm X 75mm
Numberofoutputs: 16 Digital Outputs
Acceleration/Deceleration Time: 0.1 To 6000 Seconds
Output Voltage: 0-480 V AC
Output Frequency: 0-400 Hz
Manufacturer: Siemens
Connectivity: Wi-Fi, Ethernet, Serial
Controlmethod: Pulse Width Modulation (PWM)
Enclosure Rating: IP20, IP54, IP65 Options
Torque Control: Available
Frequency Range: 0-400 Hz
Mounting Type: DIN Rail / Panel Mount
Communicationprotocol: Modbus, Profibus, Ethernet/IP
Highlight:

Mitsubishi FR-F840 inverter 110-132kW

,

VFD drive 3x380-500V industrial

,

Mitsubishi variable frequency drive with warranty
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-F840-02600-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description

FA-Inverter: Inverter

Series FR-F800 SERIES
Type FR-F800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 260
Rated Output Current LD (A) 216
Rated Motor Capacity SLD (kW) 132
Rated Motor Capacity LD (kW) 110
Frequency Range (Hz) 0,2–590
Control Method V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
USB 1+1 MINI
Ethernet Port 1
Built-In Network CC-LINK IE FIELD NETWORK BASIC, iQSS, SLMP, MELSOFT/FA, MODBUS/TCP, BACNET/IP
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 3150
Power Loss LD (W) 2575
Standby Power Consumption (W) 46
Protection Class IP00

Conformity

CE COMPLIANT
UL/cUL COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals DNV,ABS
UKCA COMPLIANT

Product Dimensions & Weight

Width (mm) 465
Height (mm) 620
Depth (mm) 300
Weight (kg) 55

Life Cycle

Predecessor 156605
Serial No. on the Box QR1

Campaigns

Selling Status Standard

Product Packaging

Cardboard (g) 5718,2
Other paper (g) 0
Aluminum (g) 0
Steel (g) 0
Styrofoam (g) 0
Other plastic (g) 215
Wood (g) 0
Glass (g) 0
Others (g) 0
