MITSUBISHI FR-F840-02160-2-60 Inverter; Rated Power: 90-110kW; 3x380-500V

1
MOQ
Negotiable
Price
MITSUBISHI FR-F840-02160-2-60 Inverter; Rated Power: 90-110kW; 3x380-500V
Features Gallery Product Description Chat Now
Features
Specifications
Output Frequency Range: 0-400 Hz
Frequency Range: 0-400 Hz
Control Method: V/F Control, Vector Control, Sensorless Vector Control
Soft Stop Time: 0.1 To 60 Seconds
Controlmethod: Pulse Width Modulation (PWM)
Controltype: Programmable Logic Controller (PLC)
Humidityrange: 5% To 95% Non-condensing
Type: Automation System
Scalability: Modular Expansion Supported
Input Voltage: 200-480V AC
Warranty: 12 Months,18 Months,16 Months,2 Years
Supply Voltage Type: AC
Power Range: 0.5 KW To 500 KW
Operatingtemperaturerange: -20°C To 60°C
Protection Class: IP20 To IP54
Highlight:

Mitsubishi FR-F840 VFD inverter

,

90-110kW variable frequency drive

,

380-500V industrial VFD inverter
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-F840-02160-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
FA-Inverter: Inverter
Series FR-F800 SERIES
Type FR-F800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 216
Rated Output Current LD (A) 180
Rated Motor Capacity SLD (kW) 110
Rated Motor Capacity LD (kW) 90
Frequency Range (Hz) 0,2–590
Control Method V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
USB 1+1 MINI
Ethernet Port 1
Built-In Network CC-LINK IE FIELD NETWORK BASIC, iQSS, SLMP, MELSOFT/FA, MODBUS/TCP, BACNET/IP
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 2520
Power Loss LD (W) 2100
Standby Power Consumption (W) 46
Protection Class IP00
Conformity
CE COMPLIANT
UL/cUL COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals DNV,ABS
UKCA COMPLIANT
Product Dimensions & Weight
Width (mm) 465
Height (mm) 620
Depth (mm) 300
Weight (kg) 52
Life Cycle
Predecessor 156604
Serial No. on the Box QR1
Campaigns
Selling Status Standard
Product Packaging
Cardboard (g) 5718,2
Other paper (g) 0
Aluminum (g) 0
Steel (g) 0
Styrofoam (g) 0
Other plastic (g) 215
Wood (g) 0
Glass (g) 0
Others (g) 0
