MITSUBISHI FR-F840-01800-2-60 Inverter; Rated Power: 75-90kW; 3x380-500V

1
MOQ
Negotiable
Price
MITSUBISHI FR-F840-01800-2-60 Inverter; Rated Power: 75-90kW; 3x380-500V
Features Gallery Product Description Chat Now
Features
Specifications
Inputvoltage: Typically 220V, 380V, 480V, Or 600V AC
Productname: Industrial Sensors
Dimensions: 90 Mm X 60 Mm X 75 Mm
Output Method: Relay
Expansioncapability: Modular Expansion Supported
Mounting Type: Wall-mounted Or Panel-mounted
Soft Stop Time: 0.1 To 60 Seconds
Power Range: 0.5 KW To 500 KW
Powerrating: 0.5 KW To 1000 KW (varies By Model)
Scalability: Modular Expansion Supported
Input Voltage: 200-480V AC
Operating Temperature: -10°C To 50°C
Color: Black,Grey,White
Outputfrequencyrange: 0 To 400 Hz
Inputvoltagerange: 100-240V AC
Highlight:

Mitsubishi FR-F840 VFD inverter

,

75-90kW variable frequency drive

,

380-500V industrial motor controller
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-F840-01800-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description

FA-Inverter: Inverter

Series FR-F800 SERIES
Type FR-F800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 180
Rated Output Current LD (A) 144
Rated Motor Capacity LD (kW) 75
Frequency Range (Hz) 0,2–590
Control Method V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
USB 1+1 MINI
Ethernet Port 1
Built-In Network CC-LINK IE FIELD NETWORK BASIC, iQSS, SLMP, MELSOFT/FA, MODBUS/TCP, BACNET/IP
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 2000
Power Loss LD (W) 1640
Standby Power Consumption (W) 28
Protection Class IP00

Conformity

CE COMPLIANT
UL/cUL COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals DNV,ABS
UKCA COMPLIANT

Product Dimensions & Weight

Width (mm) 435
Height (mm) 550
Depth (mm) 250
Weight (kg) 43

Life Cycle

Predecessor 156603
Serial No. on the Box QR1

Campaigns

Selling Status Standard

Product Packaging

Cardboard (g) 4908,8
Other paper (g) 0
Aluminum (g) 0
Steel (g) 0
Styrofoam (g) 0
Other plastic (g) 155
Wood (g) 0
Glass (g) 0
Others (g) 0
