MITSUBISHI FR-A840-05470-2-60 InverterAC without DC Choke;Pn:185-280kW;3x380-500V

1
MOQ
Negotiable
Price
MITSUBISHI FR-A840-05470-2-60 InverterAC without DC Choke;Pn:185-280kW;3x380-500V
Features Gallery Product Description Chat Now
Features
Specifications
Condition: New Original With Sealed
Input Points: 36 Points.
Frequency Range: 0-400 Hz
Communicationprotocol: Modbus, Profibus, Ethernet/IP
Communicationinterfaces: RS485, Modbus, Ethernet, Profibus (optional)
Safetystandards: IEC 61508, ISO 13849
Controlmethod: V/f Control, Vector Control, Sensorless Vector Control
Power Range: 0.5 KW To 500 KW
Memory: 50 KB
Mountingtype: Wall-mounted Or Panel-mounted
Efficiency: Typically 95% To 98%
Protectionfeatures: Overload, Overvoltage, Undervoltage, Short Circuit, Phase Loss
Inputtype: Digital And Analog
Operatingtemperature: -25°C To 85°C
Storage Temperature Range: -20°C To 70°C
Highlight:

Mitsubishi FR-A840 inverter drive

,

VFD without DC choke

,

380-500V variable frequency drive
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-A840-05470-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
Inverter
Series FR-A SERIES
Type FR-A800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 547
Rated Output Current LD (A) 481
Rated Output Current ND (A) 432
Rated Output Current HD (A) 361
Rated Motor Capacity SLD (kW) 280
Rated Motor Capacity LD (kW) 250
Rated Motor Capacity ND (kW) 220
Rated Motor Capacity HD (kW) 185
Control Method VECTOR CONTROL (WITH FR-A8AP)
V/F CONTROL
SOFT-PWM/HIGH FREQUENCY PWM
REAL SENSORLESS VECTOR CONTROL
PM SENSORLESS VECTOR CONTROL
MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
RS-485 OPTIONAL
USB 1+1 MINI
Ethernet Port 1
Built-In Network CC-LINK IE FIELD NETWORK
CC-LINK IE FIELD NETWORK BASIC
MODBUS/TCP
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 5850
Power Loss LD (W) 5100
Power Loss ND (W) 4550
Power Loss HD (W) 3700
Standby Power Consumption (W) 125
Protection Class IP00
Frequency Range (Hz) 0,2–590
Product Dimensions & Weight
Width (mm) 680
Height (mm) 1010
Depth (mm) 380
Weight (kg) 166
