Home /Products/Variable Frequency Drives VFD/MITSUBISHI FR-A840-03610-E2-60 Inverter AC; Pn: 110-132kW; 3x380-500V;In max: 325A; IP00

MITSUBISHI FR-A840-03610-E2-60 Inverter AC; Pn: 110-132kW; 3x380-500V;In max: 325A; IP00

1
MOQ
Negotiable
Price
MITSUBISHI FR-A840-03610-E2-60 Inverter AC; Pn: 110-132kW; 3x380-500V;In max: 325A; IP00
Features Gallery Product Description Chat Now
Features
Specifications
Display Type: LCD Or LED
Inputvoltage: Typically 200V To 600V AC
Ambient Temperature Range: -10°C To 50°C
Manufacturer: Siemens
Frequency Range: 0-400 Hz
Control Method: V/f Control, Vector Control, Sensorless Vector Control
Communicationprotocols: Modbus, Profibus, Ethernet/IP, CANopen
Part Type: Sysmac CPM2A
Powerrating: 0.5 KW To Several MW
Actual Value: Negotiabled Price
Points: 40 (24DI+16DO)
Total Points: 60 Points.
Operating Temperature: -10°C To 50°C
Model: FX5U-32MT/ES
Protection Class: IP20, IP54
Highlight:

Mitsubishi FR-A840 inverter drive

,

110-132kW VFD drive

,

380-500V variable frequency drive
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-A840-03610-E2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
Inverter
Series FR-A SERIES
Type FR-A800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 361
Rated Output Current LD (A) 325
Rated Output Current ND (A) 260
Rated Output Current HD (A) 216
Rated Motor Capacity SLD (kW) 185
Rated Motor Capacity LD (kW) 160
Rated Motor Capacity ND (kW) 132
Rated Motor Capacity HD (kW) 110
Control Method VECTOR CONTROL (WITH FR-A8AP)
V/F CONTROL
SOFT-PWM/HIGH FREQUENCY PWM
REAL SENSORLESS VECTOR CONTROL
PM SENSORLESS VECTOR CONTROL
MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
RS-485 OPTIONAL
USB 1+1 MINI
Ethernet Port 1
Built-In Network MODBUS/TCP
CC-LINK IE FIELD NETWORK BASIC
CC-LINK IE FIELD NETWORK
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 4050
Power Loss LD (W) 3600
Power Loss ND (W) 2800
Power Loss HD (W) 2250
Standby Power Consumption (W) 78
Protection Class IP00
Frequency Range (Hz) 0,2–590
Product Dimensions & Weight
Width (mm) 465
Height (mm) 740
Depth (mm) 360
Weight (kg) 78
