MITSUBISHI FR-A840-02160-2-60 Inverter AC without DC Choke;Pn:55-110kW

1
MOQ
Negotiable
Price
MITSUBISHI FR-A840-02160-2-60 Inverter AC without DC Choke;Pn:55-110kW
Features Gallery Product Description Chat Now
Features
Specifications
Communication Protocols: Modbus, Profibus, Ethernet/IP
Manufacturer: Siemens
Frequencyrange: 0 To 400 Hz Or Higher
Harmonic Distortion: <5%
Display: Optional LCD Or LED Indicators
Productname: Programmable Logic Controller (PLC)
Powerrating: 0.5 KW To Several MW
Coolingmethod: Air-cooled Or Liquid-cooled
Material: Stainless Steel, Plastic, Aluminum
Weight: Varies By Model
Mountingtype: Wall-mounted Or Panel-mounted
Points: 40 (24DI+16DO)
Output Method: Relay
Inputtype: Digital And Analog
Input Frequency: 50/60 Hz
Highlight:

Mitsubishi FR-A840 inverter drive

,

VFD without DC choke

,

55-110kW variable frequency drive
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-A840-02160-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description

FA-Inverter: Inverter

Series FR-A SERIES
Type FR-A800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 216
Rated Output Current LD (A) 180
Rated Output Current ND (A) 144
Rated Output Current HD (A) 110
Rated Motor Capacity SLD (kW) 110
Rated Motor Capacity LD (kW) 90
Rated Motor Capacity ND (kW) 75
Rated Motor Capacity HD (kW) 55
Frequency Range (Hz) 0,2–590
Control Method VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
RS-485 OPTIONAL
USB 1+1 MINI
Ethernet Port 1
Built-In Network MODBUS/TCP, CC-LINK IE FIELD NETWORK BASIC, CC-LINK IE FIELD NETWORK
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 2520
Power Loss LD (W) 2100
Power Loss ND (W) 1790
Power Loss HD (W) 1350
Standby Power Consumption (W) 46
Protection Class IP00

Conformity

CE COMPLIANT
UL/cUL COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals ABS,BV,DNV GL,LR,NK
UKCA COMPLIANT

Product Dimensions & Weight

Width (mm) 465
Height (mm) 620
Depth (mm) 300
Weight (kg) 52

Life Cycle

Predecessor 266756
Serial No. on the Box QR1

Campaigns

Selling Status Standard

Product Packaging

Cardboard (g) 5718,2
Other paper (g) 0
Aluminum (g) 0
Steel (g) 0
Styrofoam (g) 0
Other plastic (g) 215
Wood (g) 0
Glass (g) 0
Others (g) 0
