MITSUBISHI FR-A840-01160-2-60 Inverter AC; Pn: 37-55kW; 3x380-500V;In max: 116A;(45kW; 86A); IP00

1
MOQ
Negotiable
Price
MITSUBISHI FR-A840-01160-2-60 Inverter AC; Pn: 37-55kW; 3x380-500V;In max: 116A;(45kW; 86A); IP00
Features Gallery Product Description Chat Now
Features
Specifications
Soft Start Time: 0.1 To 60 Seconds
Actual Price: Negotiabled
Output Frequency: 0-400 Hz
Storage Temperature Range: -20°C To 70°C
Expansioncapability: Modular Expansion Supported
Humidity Range: 0-95% Non-condensing
Frequency Range: 0 To 400 Hz
Output Typt: Relay
Power Supply Voltage: 100 – 240VAC.
Material: Stainless Steel, Plastic, Aluminum
Display: Optional LCD Or LED Indicators
Communicationprotocol: Modbus, Profibus, Ethernet/IP
Enclosure Rating: IP20, IP54, IP65 Options
Efficiency: Up To 98%
Braking Method: Regenerative Braking Or Dynamic Braking
Highlight:

Mitsubishi FR-A840 inverter drive 37-55kW

,

3-phase VFD 380-500V 116A

,

industrial AC drive IP00 rated
Basic Infomation
Place of Origin: China
Brand Name: MITSUBISHI
Model Number: FR-A840-01160-2-60
Document: ib0600626g.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
FA-Inverter: Inverter
Series FR-A SERIES
Type FR-A800-E INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 500
Max. Permissible Voltage (V) 550
Current Type AC
Phases 3
Rated Output Current SLD (A) 116
Rated Output Current LD (A) 106
Rated Output Current ND (A) 86
Rated Output Current HD (A) 71
Rated Motor Capacity SLD (kW) 55
Rated Motor Capacity LD (kW) 55
Rated Motor Capacity ND (kW) 45
Rated Motor Capacity HD (kW) 37
Frequency Range (Hz) 0,2–590
Control Method VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter YES
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display FR-DU08
Display Type 5 DIGITS LED (12 SEGMENT)
PLC Function YES
Program Memory 6K
Program Memory Unit STEPS
Integrated Digital Inputs 12
Digital Outputs (Transistor) 5
Digital Outputs (Relay) 2
Integrated Analogue Inputs 3
Integrated Analogue Outputs 2
IO Type of Terminal Block SPRING CLAMP
Expandable YES
RS-485 OPTIONAL
USB 1+1 MINI
Ethernet Port 1
Built-In Network CC-LINK IE FIELD NETWORK BASIC, MODBUS/TCP, SLMP, iQSS
Leakage Current (mA) 35(DELTA) / 2(STAR)
Power Loss SLD (W) 1340
Power Loss LD (W) 1220
Power Loss ND (W) 1020
Power Loss HD (W) 860
Standby Power Consumption (W) 28
Protection Class IP00
Conformity
CE COMPLIANT
UL/cUL COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals ABS,BV,DNV GL,LR,NK
UKCA COMPLIANT
Product Dimensions & Weight
Width (mm) 435
Height (mm) 550
Depth (mm) 250
Weight (kg) 41
Life Cycle
Predecessor 266754
Serial No. on the Box QR1
Campaigns
Selling Status Standard
Product Packaging
Cardboard (g) 4908,8
Other paper (g) 0
Aluminum (g) 0
Steel (g) 0
Styrofoam (g) 0
Other plastic (g) 155
Wood (g) 0
Glass (g) 0
Others (g) 0
