Home /Products/Variable Frequency Drives VFD/Danfoss 134F2978 Frequency converter VLT® AutomationDrive FC-(360) 360 5.5 KW / 7.5 HP, (T4) 380-480VAC

Danfoss 134F2978 Frequency converter VLT® AutomationDrive FC-(360) 360 5.5 KW / 7.5 HP, (T4) 380-480VAC

1
MOQ
Negotiable
Price
Danfoss 134F2978 Frequency converter VLT® AutomationDrive FC-(360) 360 5.5 KW / 7.5 HP, (T4) 380-480VAC
Features Gallery Product Description Chat Now
Features
Specifications
Enclosure Rating: IP20 To IP54
Display Type: LCD Or LED Display
Communication Protocols: Modbus, Profibus, Ethernet/IP
Input Frequency: 50/60 Hz
Cooling Method: Forced Air Cooling
Output Frequency: 0-400 Hz
Power Rating: 0.5 KW To 500 KW
Operating Temperature Range: -10°C To 50°C
Input Voltage: 200-480V AC
Harmonic Mitigation: Built-in DC Choke Or External Filter Options
Output Voltage: 0-480V AC
Overload Capacity: 150% For 1 Minute
Protection Features: Overvoltage, Undervoltage, Overcurrent, Short Circuit, Overload
Mounting Type: Wall-mounted Or Panel-mounted
Control Method: V/f Control, Vector Control, Sensorless Vector Control
Highlight:

Danfoss VLT AutomationDrive FC-360

,

5.5 KW frequency converter

,

380-480VAC variable frequency drive
Basic Infomation
Place of Origin: China
Brand Name: Danfoss
Model Number: 134F2978
Document: ID362147513251-0101.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
Danfoss VLT® AutomationDrive FC-360 Frequency Converter
Key Specifications
Power: 5.5 KW / 7.5 HP
Voltage: 380-480VAC (Three Phase)
Enclosure: IP20 / Chassis
DrivePro Category: Exchange Unit
Product Details
Gross Weight
4.21 Kilogram
Net Weight
3.763 Kilogram
Volume
12.965 Liter
EAN
5710107427338
Technical Configuration
Feature Code Description
Product Group FC- VLT® AutomationDrive FC-
Series 360 (360) 360
Power H High Overload
Power Size 5K5 5.5 KW / 7.5 HP
Voltage T4 (T4) 380-480VAC (Three Phase)
Enclosure E20 IP20 / Chassis
RFI Filter H2 RFI Class A2
Brake & Stop B (B) Brake Chopper
Display X No Display (No Blind Cover)
Coating C (C) Coated PCB
Mains Option D Loadsharing
Identification Codes
Typecode Part 1
FC-360H5K5T4E20H2BXC
Typecode Part 2
DXXSXXXXAXBX
Model Code 01
FC-360H5K5T4E20H2BXC
Model Code 02
DXXSXXXXAXBX
Tag:

Compact Frequency Inverter

Vector Frequency Inverter

Variable Frequency Drive VFD
