Home /Products/Variable Frequency Drives VFD/Danfoss 134F2970 Frequency converter VLT® AutomationDrive FC-(360) 360 0.37 KW / 0.50 HP, (T4) 380-480VAC (Three phased)

Danfoss 134F2970 Frequency converter VLT® AutomationDrive FC-(360) 360 0.37 KW / 0.50 HP, (T4) 380-480VAC (Three phased)

1
MOQ
Negotiable
Price
Danfoss 134F2970 Frequency converter VLT® AutomationDrive FC-(360) 360 0.37 KW / 0.50 HP, (T4) 380-480VAC (Three phased)
Features Gallery Product Description Chat Now
Features
Specifications
Input Voltage: 200-480 V AC
Ambient Operating Temperature: -10°C To 50°C
Mounting Type: Wall-mounted Or Panel-mounted
Output Frequency: 0-400 Hz
Control Method: V/f Control, Vector Control, Sensorless Vector Control
Input Frequency: 50/60 Hz
Overload Capacity: 150% For 1 Minute
Protection Class: IP20 To IP54
Communication Protocols: Modbus, Profibus, Ethernet/IP
Output Voltage: 0-480 V AC
Acceleration/Deceleration Time: 0.1 To 6000 Seconds
Display Type: LCD Or LED Display
Harmonic Mitigation: Built-in Filters Or External Filters
Power Rating: 0.5 KW To 500 KW
Cooling Method: Forced Air Cooling
Highlight:

Danfoss VLT AutomationDrive FC-360

,

0.37 KW frequency converter

,

three-phase VFD 380-480VAC
Basic Infomation
Place of Origin: China
Brand Name: Danfoss
Model Number: 134F2970
Document: ID500939063892-0101.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description
Danfoss 134F2970 Frequency Converter
VLT® AutomationDrive FC-(360) 360 Series - 0.37 KW / 0.50 HP, (T4) 380-480VAC Three Phase
Product Overview
The Danfoss VLT® AutomationDrive FC-360 is a high-performance frequency converter designed for industrial automation applications. This model features high overload capability and robust construction for reliable operation in demanding environments.
Technical Specifications
Parameter Value
Product Group VLT® AutomationDrive FC-
Series (360) 360
Power Rating 0.37 KW / 0.50 HP (High Overload)
Voltage (T4) 380-480VAC Three Phase
Enclosure IP20 / Chassis
RFI Filter RFI Class A2
Brake & Stop (B) Brake Chopper
Display No Display (No Blind Cover)
Coating (C) Coated PCB
Control Card Standard Control Card
Frame Size J1
Physical Characteristics
Gross Weight: 2.63 kg
Net Weight: 2.58 kg
Volume: 9.337 L
EAN: 5710107427154
Additional Features
Mains Option: Loadsharing
Software: Latest Release - Standard Software
Language Pack: Standard Language Pack
Cable Entries: Standard
Product Identification
Typecode Part 1: FC-360HK37T4E20H2BXC
Typecode Part 2: DXXSXXXXAXBX
Model Code: FC-360HK37T4E20H2BXC DXXSXXXXAXBX
Tag:

Compact Frequency Inverter

Vector Frequency Inverter

Variable Frequency Drive VFD
