Home /Products/Variable Frequency Drives VFD/Milano KV90-090G-4-PV 380V Three Phase Overall Dimensions：610H(mm) 265W(mm) 280D(mm) Mounting Dimensions：590A(mm) 200B(mm)

Milano KV90-090G-4-PV 380V Three Phase Overall Dimensions：610H(mm) 265W(mm) 280D(mm) Mounting Dimensions：590A(mm) 200B(mm)

1pcs
MOQ
Negotiable
Price
Milano KV90-090G-4-PV 380V Three Phase Overall Dimensions：610H(mm) 265W(mm) 280D(mm) Mounting Dimensions：590A(mm) 200B(mm)
Features Gallery Product Description Chat Now
Features
Specifications
Protection Class: IP20 To IP65
Harmonic Mitigation: Built-in DC Choke Or External Filter
Control Method: V/F Control, Vector Control, Sensorless Vector Control
Input Frequency: 50/60 Hz
Cooling Method: Forced Air Cooling
Mounting Type: Wall-mounted Or Panel-mounted
Display Type: LCD Or LED Display
Output Voltage: 0-480 V AC
Operating Temperature Range: -10°C To 50°C
Acceleration/Deceleration Time: 0.1 To 6000 Seconds
Overload Capacity: 150% For 1 Minute
Communication Protocols: Modbus, Profibus, Ethernet/IP
Power Rating: 0.5 KW To 500 KW
Input Voltage: 200-480 V AC
Output Frequency: 0-400 Hz
Highlight:

380V three phase VFD drive

,

Milano KV90 variable frequency drive

,

industrial VFD with mounting dimensions
Basic Infomation
Place of Origin: China
Brand Name: Milano
Model Number: KV90-090G-4-PV
Document: Datesheet.xlsx
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Milano KV90-090G-4-PV 380V Three Phase Variable Frequency Drive
Physical Dimensions: 610H(mm) × 265W(mm) × 280D(mm)
Mounting Dimensions: 590A(mm) × 200B(mm)
Product Specifications
Parameter -S2 (220V single-phase) -I (220V single-phase) -4 (380V three-phase)
Input voltage range (PV) 190-450V 190-450V 270-900V
Recommended Voc voltage 300-400V 300-400V 450-700V
Optimum MPPT voltage 310V 310V 540V
Maximum MPPT efficiency up to 99% up to 99% up to 99%
Start-up voltage 240V 240V 350V
Minimum Operating Voltage 190V 190V 270V
Input voltage range (AC) 1PH 220-240V(±10%) 1PH 220-240V(±10%) 3PH 380-480V(±10%)
Input voltage frequency 50/60Hz 50/60Hz 50/60Hz
Output voltage range 0-230V 0-230V 0-480V
Output frequency range 0-400Hz 0-400Hz 0-400Hz
Output power range 0.75-4kW 0.75-4kW 0.75-185kW
Rated Output Current Specifications
Power (kW) -S2 Current (A) -I Current (A) -4 Current (A)
0.75952.7
1.51373.7
2.218105
323137
428179
5.5402513
7.5603217
11754525
15906032
18.51107537
221509045
3017611060
3721015075
45176110
55210150
75176
90210
110250
132300
160340
185400
Technical Features
Motor Compatibility
  • -S2 Model: Single phase motor
  • -I and -4 Models: Asynchronous motors, Permanent magnet synchronous motor
Control Modes
  • V/F control
  • Open-Loop Vector Control
  • Closed-Loop Vector Control
Overload Capacity
  • 150% of rated load for 60 seconds
  • 180% overload capacity for 10 seconds
  • 200% overload capacity for 0.5 seconds
Environmental Specifications
  • Installation: Wall-mounted
  • Protection Class: IP20
  • Working Temperature: -10°C to +50°C (derating 2% per 1°C above 40°C)
  • Cooling Method: Forced air cooling
  • Humidity: 20% to 95% RH (condensation free)
  • Installation Altitude: Up to 1000m (derating 1% per 100m above 1000m)
