Home /Products/Variable Frequency Drives VFD/Milano KV90-4D0G-S2-PV 220V Single Phase Overall Dimensions：295H(mm) 165W(mm) 205D(mm) Mounting Dimensions：280A(mm) 145B(mm)

Milano KV90-4D0G-S2-PV 220V Single Phase Overall Dimensions：295H(mm) 165W(mm) 205D(mm) Mounting Dimensions：280A(mm) 145B(mm)

1pcs
MOQ
Negotiable
Price
Milano KV90-4D0G-S2-PV 220V Single Phase Overall Dimensions：295H(mm) 165W(mm) 205D(mm) Mounting Dimensions：280A(mm) 145B(mm)
Features Gallery Product Description Chat Now
Features
Specifications
Input Voltage: 200-480 V AC
Acceleration/Deceleration Time: 0.1 To 6000 Seconds
Overload Capacity: 150% For 1 Minute
Harmonic Mitigation: Built-in Filters Or External Options
Output Voltage: 0-480 V AC
Cooling Method: Forced Air Cooling
Power Rating: 0.5 KW To 500 KW
Protection Class: IP20 To IP54
Control Method: V/f Control, Vector Control, Sensorless Vector Control
Mounting Type: Wall-mounted Or Panel-mounted
Ambient Temperature Range: -10°C To 50°C
Output Frequency: 0-400 Hz
Display Type: LCD Or LED Display
Communication Protocols: Modbus, Profibus, Ethernet/IP
Input Frequency: 50/60 Hz
Highlight:

220V single phase VFD

,

Milano KV90 variable frequency drive

,

compact VFD with mounting dimensions
Basic Infomation
Place of Origin: China
Brand Name: Milano
Model Number: KV90-4D0G-S2-PV
Document: Datesheet.xlsx
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Milano KV90-4D0G-S2-PV 220V Single Phase Variable Frequency Drive
Physical Dimensions
Overall Dimensions: 295H (mm) × 165W (mm) × 205D (mm)
Mounting Dimensions: 280A (mm) × 145B (mm)
Technical Specifications
Parameter -S2 (220V Single-Phase) -I (220V Single-Phase) -4 (380V Three-Phase)
Input Voltage Range (PV) 190-450V 190-450V 270-900V
Recommended Voc Voltage 300-400V 300-400V 450-700V
Optimum MPPT Voltage 310V 310V 540V
Maximum MPPT Efficiency up to 99% up to 99% up to 99%
Start-up Voltage 240V 240V 350V
Minimum Operating Voltage 190V 190V 270V
Input Voltage Range (AC) 1PH 220-240V(±10%) 1PH 220-240V(±10%) 3PH 380-480V(±10%)
Input Voltage Frequency 50/60Hz 50/60Hz 50/60Hz
Output Voltage Range 0-230V 0-230V 0-480V
Output Frequency Range 0-400Hz 0-400Hz 0-400Hz
Output Power Range 0.75-4kW 0.75-4kW 0.75-185kW
Rated Output Current by Power Rating
Power (kW) Rated Current (-S2) Rated Current (-I) Rated Current (-4)
0.75952.7
1.51373.7
2.218105
323137
428179
5.5402513
7.5603217
11754525
15906032
18.51107537
221509045
3017611060
3721015075
45176110
55210150
75176
90210
110250
132300
160340
185400
Performance Features
Motor Compatibility
  • -S2 Model: Single phase motor
  • -I Model: Asynchronous motors, Permanent magnet synchronous motor
Control Modes
  • V/F control
  • Open-Loop Vector Control
  • Closed-Loop Vector Control
Overload Capacity
  • 150% of rated load for 60 seconds
  • 180% overload capacity for 10 seconds
  • 200% overload capacity for 0.5 seconds
Environmental Specifications
Installation: Support wall-mounted
Protection Class: IP20
Working Temperature: -10°C to +50°C (derating 2% per 1°C above 40°C)
Cooling Method: Forced air cooling
Humidity: 20% to 95% RH (condensation free)
Installation Environment: Less than 1000m (derating 1% per 100m above 1000m)
