Milano KV90S-2D2G-S2-PV 220V Single Phase Overall Dimensions：240H(mm) 125W(mm) 170D(mm)

The Milano KV90S-2D2G-S2-PV is a high-performance compact variable frequency drive from the KV90S series. It is designed to control the rotation speed and torque of 3-phase asynchronous motors by converting single-phase 220V AC input into 3-phase variable voltage/frequency output. By adjusting output frequency within 0–400Hz, it realizes flexible speed regulation, soft start/stop of motors, and effective energy saving. Built-in standard Modbus RTU communication interface supports seamless connection with PLC, HMI and other automation equipment for centralized monitoring and remote control. Optimized for simple machinery, HVAC, conveying and pumping equipment, it is a plug-and-play compact drive for small power automation applications, especially for sites with only single-phase power supply.

• Single-Phase Input, Three-Phase Output Accepts 1-phase 220V AC input and drives 3-phase motors, ideal for residential, commercial and light industrial sites without 3-phase power infrastructure.
• Wide Output Frequency Range 0–400 Hz Suitable for common motors and high-speed spindle small machinery, delivering stable low-speed torque.
• Compact Space-saving Design With integrated heat sink structure, easy DIN rail or panel mounting, overall dimensions 240H × 125W × 170D mm, fits limited cabinet installation space.
• Multiple Control Modes V/F control, quadratic curve control for fan & pump, sensorless flux vector control. Built-in adjustable PID regulator.
• Rich Built-in Protection Functions Overvoltage, undervoltage, overcurrent, overheating, motor overload, short-circuit protection.
• Energy Saving Performance Dynamic power optimization for pump and fan loads, achieve up to 30% energy reduction.
• Easy Commissioning Onboard LED display & operation keypad; quick parameter setup and fault code display for easy troubleshooting.
• Global Standard Certifications Complies with CE, RoHS, suitable for worldwide export projects.

• Packaging Machinery
• Material Handling & Small Conveyors
• HVAC & Ventilation Systems
• Water Treatment & Small Pumps
• Textile Equipment
• Printing Machinery
• Food & Beverage Processing
• General Automatic Commercial Equipment

• Small conveyor belts
• Centrifugal fans
• Circulation pumps
• Packaging labelling machines
• Access barriers
• Small mixers
• Treadmill equipment
• Oven exhaust fans
• Spindle drives

• Net weight: approx. 1.8 kg / pc
• Single carton gross weight: approx. 2.1 kg / pc
• Original brand new, individual export carton, 12-month manufacturer warranty.
