Milano KV90S-0D75G-S2-PV 220V Single Phase Overall Dimensions：205H(mm) 105W(mm) 165D(mm)

The Schneider Electric ATV12HU15M3 is a compact variable frequency drive (VFD) from the Altivar 12 series, engineered specifically for controlling the speed and torque of 3-phase asynchronous motors. Operating with an input of 200–240V AC, it delivers precise output frequency regulation from 0.5 to 400 Hz, enabling smooth soft starts/stops and significant energy savings. With its integrated Modbus RTU communication and plug-and-play design, this 1.5 kW / 2 HP drive serves as an ideal motion control solution for small machinery, HVAC systems, conveying equipment, and pumping applications requiring reliable automation integration.

• Integrated Modbus RTU Communication
  Built-in RS485 interface supports multiple baud rates (up to 38.4 kbps), enabling seamless networking with PLCs and HMIs for centralized monitoring without additional communication cards.
• Wide Frequency Range 0.5–400 Hz
  Versatile output frequency suitable for both standard industrial motors and high-speed spindle applications in small machinery.
• Ultra-Compact Space-Saving Design
  Integrated heat sink structure allows for DIN rail or panel mounting, maximizing cabinet space efficiency in tight installations.
• Advanced Multi-Mode Control
  Supports V/F control, quadratic V/F curve (optimized for fans/pumps), and sensorless flux vector control with a built-in adjustable PID regulator for precise process management.
• Comprehensive Motor Protection
  Embedded safeguards against overvoltage, undervoltage, overcurrent, overheating, motor overload, and short circuits ensure long-term equipment reliability.
• Energy Optimization Technology
  Dynamic power adjustment for variable torque loads achieves up to 30% energy reduction compared to fixed-speed operation.
• Rapid Commissioning & Maintenance
  Onboard LED display with rotary knob enables quick parameter setup; SoMove software compatibility allows parameter copying to minimize downtime.
• Global Certification Compliance
  Certified to IEC, UL, CSA, and RoHS standards, ensuring suitability for international export projects and diverse regulatory environments.

Applicable Industries:

• Packaging & Labeling Machinery
• Material Handling & Small Conveyors
• HVAC & Ventilation Systems
• Water Treatment & Circulation Pumps
• Textile & Printing Equipment
• Automatic Commercial Equipment

Typical Equipment Applications:
Small conveyor belts, centrifugal fans, circulation pumps, packaging labelling machines, access barriers, small mixers, treadmill equipment, oven exhaust fans.

• Net Weight: 1.42 kg / p
• Gross Weight: 1.6 kg / pc (single carton)
• Packaging: Original brand new individual export carton
• Warranty: 12-month manufacturer warranty
• Supply Note: Suitable for industrial automation component warehouse stocking and export DDP bulk shipment
