Home /Products/Servo Systems/Honeywell ML7420A8088-E Servo Actuator IP65 With EtherCAT Communication 6000 RPM Speed

Honeywell ML7420A8088-E Servo Actuator IP65 With EtherCAT Communication 6000 RPM Speed

1 pcs
MOQ
Negotiable
Price
Honeywell ML7420A8088-E Servo Actuator IP65 With EtherCAT Communication 6000 RPM Speed
Features Gallery Product Description Chat Now
Features
Specifications
Communicationinterface: EtherCAT, CANopen, Modbus
Protectionrating: IP65 Or Higher
Application: Robotics, CNC Machines, Automation
Productname: Servo Systems
Efficiency: Up To 95%
Responsetime: Less Than 1 Ms
Speedrange: 0 To 6000 RPM
Mountingtype: Flange Or Foot Mount
Feedbackdevice: Encoder Or Resolver
Torquerange: 0.1 Nm To 1000 Nm
Controlmethod: Closed-loop Feedback
Voltagerange: 24V To 480V
Powersupply: AC/DC Depending On Model
Operatingtemperature: -10°C To 50°C
Type: Motion Control System
Highlight:

Honeywell ML7420A8088-E

,

Servo Actuator IP65

,

Servo Actuator 6000 RPM
Basic Infomation
Brand Name: Honeywell
Certification: Brand new original
Model Number: ML7420A8088-E
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Honeywell ML7420A8088-E Servo Actuators
Core Specifications
Electrical and Control
Parameters Specifications Description
Power Supply 24 VAC ±15%, 50/60 Hz Low power consumption, only 5 VA
Input Signal 0(2)~10 VDC Voltage-type control, input impedance 100 kΩ
Feedback Signal 2~10 VDC Position feedback, maximum load 1 mA
Action Direction Positive/Reverse action selectable Adaptable to different valve logic
Fail-safe Position Selectable when signal is lost Stay in place / Fully open / Fully closed
Mechanical and Physical
Parameters Specifications Description
Rated Thrust 600 N Standard shut-off force
Rated Stroke 20 mm Linear displacement
Running Time 60 seconds Full stroke time
Protection Rating IP54 Dustproof and splashproof, suitable for rack/field installation
Weight 1.3 kg Net weight; Gross weight approx. 3 kg
Dimensions Approx. 135*67.4*242 mm High-temperature kit not included
Manual operation with emergency manual knob.
Environment and Certifications
Parameter Specifications Description
Operating Temperature -10°C ~ +50°C 5%~95% RH, non-condensing
Media Temperature Maximum 150°C, up to 220°C with high-temperature kit
Storage Temperature -40°C ~ +70°C
Certifications CE, UL, c-Tick Global market access
Core Functions and Features
  • Stroke Adaptive: Automatically calibrates valve stroke, resolving feedback and input mismatch issues
  • Maintenance-Free Design: Low power consumption, no easily damaged parts, suitable for long-term continuous operation
  • Direct Coupling: No connecting rod required, direct connection to Honeywell linear valves, easy installation
  • Corrosion-Resistant Housing: ABS-FR flame-retardant top cover + cast aluminum bracket, suitable for industrial environments
  • End-Point Limit: Built-in mechanical + electronic dual limit, protecting the valve and actuator
Typical Application Scenarios
  • HVAC: Water/steam valve regulation for fan coil units, air handling units, and chillers
  • Industrial Processes: Flow/temperature control for hot water, steam, and thermal oil systems
  • Building Automation: Forming a closed-loop control system with a DDC controller
Foreign Trade Logistics and Supply
  • Packaging: Standard industrial cardboard box, gross weight approximately 3 kg, volume approximately 0.005 m³, for easy DDP/FOB quoting
  • Supply: Hot-selling items, not discontinued; standard delivery time 1–10 working days; bulk orders supported
  • Warranty: 12-month manufacturer's warranty
