Honeywell HD660-S-0037-A 3.7KW 220V Frequency Converter

1 pcs
MOQ
Negotiable
Price
Honeywell HD660-S-0037-A 3.7KW 220V Frequency Converter
Features Gallery Product Description Chat Now
Features
Specifications
Communicationprotocols: Modbus, Profibus, Ethernet/IP, CANopen
Outputfrequency: 0 To 400 Hz Or Higher
Displaytype: LCD Or LED Display For Status And Parameter Settings
Inputvoltage: Typically 200-600V AC
Outputvoltage: Variable, Up To Input Voltage
Mountingtype: Wall-mounted, Panel-mounted, Or Standalone
Protectionfeatures: Overvoltage, Undervoltage, Overcurrent, Short Circuit, Thermal Overload
Application: Pumps, Fans, Conveyors, HVAC, Industrial Machinery
Efficiency: Typically 95% To 98%
Function: Control Motor Speed And Torque By Varying Motor Input Frequency And Voltage
Controlmethod: V/f Control, Vector Control, Direct Torque Control
Productname: Variable Frequency Drive (VFD)
Powerrating: 0.5 KW To Several MW
Dimensions: Varies By Power Rating, Typically Compact Design
Coolingmethod: Air Cooled Or Liquid Cooled
Highlight:

Honeywell 3.7KW frequency converter

,

220V variable frequency drive

,

Honeywell HD660 VFD with warranty
Basic Infomation
Brand Name: Honeywell
Certification: Brand new original
Model Number: HD660-S-0037-A
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Honeywell HD660-S-0037-A 3.7KW 220V Frequency Converter
Core Electrical Specifications
Parameter Specification
Rated Output Power (Constant Torque) 3.7kW
Rated Output Current (Constant Torque) 16A
Maximum Frequency Vector Control: 0~320Hz; V/F Control: 0~3200Hz
Carrier Frequency 1kHz~16kHz (Automatically Adjustable)
Starting Torque 0.5Hz/150% (No PG, Constant Torque)
Speed Range 1:100 (No PG)
Speed Stabilization Accuracy ±0.5% (No PG)
Overload Capacity Constant Torque: 150%/60s, 180%/3s; Square Torque: 120%/60s, 150%/3s
Control Power Supply 24VDC (Built-in)
Communication Interface Standard RS485, Supports Modbus-RTU (up to 115200bps)
Protection Rating IP20 (Rack Mounted)
Physical and Installation Specifications
Parameter Value
Dimensions (Width × Height × Depth) 100mm × 183mm × 143mm
Installation Dimensions (Hole Spacing × Hole Diameter) 90mm × 173mm, Ø5mm
Net Weight Approx. 2.8kg
Gross Weight (including standard packaging) Approx. 3.5kg
Packaging Dimensions 180mm × 150mm × 120mm
Cooling Method Forced air cooling (independent air duct)
Ambient Temperature -20℃~+50℃ (Derating required above 50℃)
Advanced Functional Features
  • Control Functions: Built-in PID closed-loop, 16-speed, S-curve acceleration/deceleration, speed tracking restart, automatic voltage regulation (AVR), rapid current limiting
  • I/O Configuration: 6 digital inputs (1 supporting 100kHz high-speed pulse), 2 analog inputs, 1 digital output, 1 relay output, and 1 analog output
  • Comprehensive Protection: Motor short-circuit detection, output phase loss protection, overcurrent protection, overvoltage protection, undervoltage protection, overheat protection, and overload protection
  • Environmental Compatibility: Coated PCB board with independent airflow, dust and oil resistant, requires no derating up to 50℃
  • Single-Phase Advantage: Designed specifically for single-phase 220V power supply scenarios, suitable for small devices and residential/commercial power supply environments
This 3.7KW frequency converter is engineered for precision motor control applications, offering robust performance in industrial and commercial settings with single-phase 220V power requirements.
